Product description The white Atlas Sound FAP8CXT Strategy II Series 8" 60W high-sensitivity coaxial ceiling speaker with high-performance 70.7V / 100V transformer offers clear reproduction of voice and music signals for use in offices, classrooms, and retail shops. The 8" polypropylene cone-type driver and coaxially mounted tweeter are housed by a sturdy metal enclosure, which is tuned and ported for extended low-frequency range. A built-in 2 kHz crossover ensures proper routing of frequencies to the transducers. The FAP8CXT yields a frequency response of 60 Hz to 15 kHz, with adjustable power output settings ranging from an 8-Ohm transformer bypass to a maximum of 60W at 70.7V.The front-mounted tap selector switch is concealed and protected by a press-fit steel grille. System wiring is accommodated by the detachable 4-pole Euroblock connector, located beneath a conduit access panel. A C-Ring / V-Rail tile bridge mounting system is included for easy installation in drop tile or sheetrock ceilings. - Extended Bass Response
- The deep-drawn galvanized metal enclosure is tuned and ported to give the listener an extended bass response.
- Low Distortion
- The FAP8CXT features a curvilinear, polypropylene cone for lower harmonic distortion and a built-in 2 kHz crossover network for proper frequency transition between the two transducers. A 1" exit compression high-frequency driver is coupled to a specially designed conical waveguide horn to provide improved output and accurate high-frequency reproduction.
- Internal Transformer with Selectable Taps
- The 70.7V / 100V internal transformer offers power taps at 1.9, 3.8, 7.5, 15, 30, or 60 watts, as well as an 8-Ohm setting that bypasses the transformer for direct-coupled operation.
- Easy-to-Access Tap Selector
- A convenient, front-mounted, multi-position selector switch allows tap adjustment without having to remove the speaker from the ceiling.
- Sturdy Construction
- The speaker is protected by a press-fit steel mesh grille and housed in an 18-gauge metal enclosure.
- Detachable 4-Pole Connector
- The detachable 4-pole Euroblock (Phoenix-style) connector lets you pre-wire your speaker system and is easily utilized for daisy-chaining.
- "Trap Door" Input Section
- The "trap door" input section accommodates connection of rigid or flexible conduit to the recessed terminal cup.
- Easy Installation
- The FAP8CXT is easily installed in drop tile or sheetrock ceilings via the included C-Ring / V-Rail tile bridge and "dog leg" mounting system. A 1/4"-20 drop forged eyebolt is factory installed into the top of the enclosure for an additional suspension point when used in drop tile ceilings or for pendant mounting.
UPC: 612079183883 In the Box Atlas Sound FAP8CXT Strategy II Series 8" Compression Driver Coaxial Ceiling Speaker (White) C-Ring / V-Rail Tile Bridge Mounting System Limited 5-Year Warranty Brochure PDF 576.8kbrzsrzecvedeezxabctrcryvssb Table of Contents
|
Upload User Manual
Have you got an user manual for the Atlas Sound FAP8CXT Strategy II Series 8" Compression Driver Coaxial Ceiling Speaker in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersAtlas Sound FAP8CXT Specs | Speaker Type | Passive coaxial | | Woofer | 8" / 20.3 cm polypropylene cone with 1.4" / 3.5 cm voice coil | | Tweeter | 1" / 2.5 cm exit compression high-frequency driver | | Dispersion | 90° conical (2 kHz octave band) | | Frequency Response | 60 Hz to 15 kHz (
