Product description The white Atlas Sound GD87W is a passive, non-shielded 8" ceiling speaker with an 8W multi-tap transformer designed for voice amplification and background music reproduction in a variety of environments ranging from academic institutions to industrial buildings. When driven by a 70V/100V power amplifier (available separately), the 8" treated paper woofer and 3" tweeter yield a nominal frequency range of 45 Hz to 19 kHz. A built-in crossover network ensures proper distribution of frequencies to the speaker components. With a 120° dispersion pattern and a pre-installed CRS baffle, the GD87W is well suited for installation in tile bridges, mounting rings, and enclosures. The color-coded 6" wire lead ensures simple wiring at the desired tap setting. The GD87W includes mounting hardware for easy installation. - Multi-purpose coaxial loudspeaker for voice transmission, music, and signal reproduction in commercial, industrial, and institutional applications
- Optimized to produce sonic quality similar to the legendary C803A speaker
- 45 Hz to 19 kHz nominal frequency range
- High-efficiency transformer with taps at 1W, 2W, 4W, and 8W for use with constant-voltage systems
- Handles 16W RMS (25W peak)
- Factory-installed CRS baffle with concealed loudspeaker mounting studs
- Durable white powder-coated epoxy finish on baffle
- Accommodates most Atlas Sound 8" tile bridges, mounting rings, and enclosures
UPC: 612079179985 In the Box Atlas Sound GD87W 8" 2-Way 16W Coaxial Ceiling Speaker with Baffle & 70.7V Transformer Mounting Hardware Limited 5-Year Warranty Brochure PDF 512kb Table of Contents
|
Upload User Manual
Have you got an user manual for the Atlas Sound GD87W 8" 2-Way 16W Coaxial Ceiling Speaker with Baffle & 70.7V Transformer in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersAtlas Sound GD87W Specs | Active or Passive | Passive | | Power Handling | RMS: 16 W
Peak: 25 W | | Low Frequency Driver | 8" / 20.3 cm Treated Paper with 1" / 2.5 cm Voice Coil | | High Frequency Driver | 3" / 7.6 cm | | Frequency Response | Speaker: 45 Hz to 19 kHz (Nominal)
Speaker: 55 Hz to 15 kHz (
