User Manual for Atlas Sound PA1001G - Pole-Mount Mono Channel 100W 70 100V Amplifier System Click to enlarge the picture
Contents of the user manual for the Atlas Sound PA1001G - Pole-Mount Mono
- Product category: 70-Volt Amplifiers Atlas Sound
- Brand: Atlas Sound
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Atlas Sound 70-Volt Amplifiers
|
User manual for the Atlas Sound PA1001G - Pole-Mount Mono contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Atlas Sound product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Atlas Sound user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Atlas Sound product will considerably shorten its lifespan!
|
Product description The Atlas PA1001G Mono 100W 70/100V Amplifier System features two input channels and is well suited for audio installation in commercial retail, restaurants, bars, small venues, offices or wherever a commercial audio amplifier is needed. The PA1001G features a patented hole-through design for accommodating ceiling mounted projectors. One or two units can be rack mounted allowing it to be used in more traditional applications. The system may be remotely powered (turned on) via audio or AC trigger sensors. - Ultra efficient amplification technology
- Patent pending, through chassis mounting system for use with pole-mounted projector systems
- Multivoltage power supply allows for worldwide operation
UPC: 612079186716 In the Box Atlas Sound PA1001G - Pole-Mount Mono Channel 100W 70/100V Amplifier System Limited 3-Year Warranty Guides & Manuals tqxbwqqxaevecbudxqcb Table of Contents
|
Upload User Manual
Have you got an user manual for the Atlas Sound PA1001G - Pole-Mount Mono Channel 100W 70 100V Amplifier System in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Download User ManualThe user manual for the Atlas Sound PA1001G - Pole-Mount Mono Channel 100W 70 100V Amplifier System can be downloaded in PDF format at the link stated below.
Technical parametersAtlas Sound PA1001G Specs | Power Output | 100 W at 70 V into 50 Ohms load
100 W at 100 V into 100 Ohms load RMS 1% THD | | Frequency Response ± 3dB | 30 Hz to 20 kHz (Hi-Pass filter not engaged)
100 Hz to 20 kHz (Hi-Pass filter engaged) | | THD + N | 0.2% | | Input Sensitivity | 50 mV - 320 mV (RCA unbalanced summed)
320 mV (adjustable balanced) | | Input Impedance | 10 kOhms (RCA unbalanced)
20 kOhms (Phoenix-type connector, balanced) | | Signal to Noise Ratio | -100 dB below rated output (A-weighted) | | Front Panel Controls | Power switch
Gain, Treble, Bass
Indicators: Limit, Signal, Power | | Trigger Events | Audio Turn On: 1 mV - 20 mV
AC Turn On: 100 mA | | Power Requirements | 120 VAC, 60 Hz
Power Consumption: 10 W sleep mode, 16 W active idle mode, 165 W full load 70 V
Protection Circuits: AC Fuse (T1.6A 250 V 5 mm x 20 mm), thermal, short circuit | | Dimensions | 8.5 x 1.75 x 13.5 / 216 x 45 x 343 mm | | Weight | 4.9 lb / 2.4 kg | | | | Package Weight | 6.95 lb | | Box Dimensions (LxWxH) | 17.8 x 10.7 x 3.2" |
