User Manual for Atlona Composite Video & Stereo Audio to HDMI Video Format Converter Scaler Click to enlarge the picture
Contents of the user manual for the Atlona Composite Video & Stereo Audio
- Product category: Signal Converters Atlona
- Brand: Atlona
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Atlona Signal Converters
|
User manual for the Atlona Composite Video & Stereo Audio contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Atlona product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Atlona user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Atlona product will considerably shorten its lifespan!
|
Product description The Atlona Composite Video & Stereo Audio to HDMI Video Format Converter / Scaler is designed to convert and scale a composite video (BNC) signal from a DVD, VCR, or camcorder to an HD display. It accepts input signals up to 1080p and UXGA (1600 x 1200) and provides output that matches the native resolution of the connected display. Locking BNC connectors ensure a secure and reliable connection.
Stereo audio signals are embedded into the video signal for transmission of output via a single HDMI cable. A Plug-n-Play setup ensures that the converter/scaler does not require additional software for operation. An on-screen display allows you make changes to the output resolution of signals. In addition, you can select the output for PC or HDTV display. - Key Features
-
- Converts composite video signals with stereo audio for display on a high-definition display
- Compatible with input resolutions up to 1080p and UXGA
- Supports NTSC to PAL or PAL to NTSC conversion
- Provides output which matches the native resolution of the connected display
- Locking BNC connectors for a secure and reliable connection
- Embeds stereo audio into the video signal for transmission of output via a single HDMI cable
- Plug-n-play operation with no software requirement
- On-screen controls for changing output resolution of signals
- Selectable output for PC or HDTV display
UPC: 846352002800 In the Box Atlona Composite Video & Stereo Audio to HDMI Video Format Converter / Scaler - 5V Power Supply
- BNC to RCA Adapter
- Limited 3-Year Warranty
Table of Contents
|
Upload User Manual
Have you got an user manual for the Atlona Composite Video & Stereo Audio to HDMI Video Format Converter Scaler in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersAtlona AT-HD120 Specs | Inputs | 1 x Composite video (BNC)
1 x 3.5 mm stereo audio | | Outputs | 1 x HDMI (Type-A female) | | Output Resolution | Computer (60 Hz only):
1024 X 768 (XGA)
1280 X 1024 (SXGA)
1600 X 1200 (UXGA)
Video:
480p
576p (50 Hz only)
720p
1080p (50/60 Hz) | | Power Supply | 5 VDC (110/220 VAC) | | Operating Temperature | 32 to 104ºF (0 to 40ºC) | | Dimensions (WxDxH) | 3.09 x 5.16 x 1.18" (78.5 x 131 x 30 mm) | | Weight | 0.44 lb (200 g) | | | | Package Weight | 1.55 lb | | Box Dimensions (LxWxH) | 11.1 x 7.3 x 2.9" |
