User Manual for Audient Sono USB Audio Interface For Electric Guitar Players

Click to enlarge the picture
Audient Sono USB Audio Interface For Electric Guitar Players Contents of the user manual for the Audient Sono USB Audio Interface For
  • Product category: Audio Interfaces & Systems Audient
  • Brand: Audient
  • Description and content of package
  • Technical information and basic settings
  • Frequently asked questions – FAQ
  • Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
  • Authorized service for Audient Audio Interfaces & Systems

Audient Sono USB Audio Interface For Electric Guitar Players Audient Sono USB Audio Interface For Electric Guitar Players Audient Sono USB Audio Interface For Electric Guitar Players Audient Sono USB Audio Interface For Electric Guitar Players Audient Sono USB Audio Interface For Electric Guitar Players Audient Sono USB Audio Interface For Electric Guitar Players Audient Sono USB Audio Interface For Electric Guitar Players Audient Sono USB Audio Interface For Electric Guitar Players
User manual for the Audient Sono USB Audio Interface For contain basic instructions that need to be followed during installation and operation. Before starting your appliance, the user manual should be read through carefully. Follow all the safety instructions and warnings, and be guided by the given recommendations. User manual is an integral part of any Audient product, and if it is sold or transferred, they should be handed over jointly with the product. Following the instructions for use is an essential prerequisite for protecting health and property during use, as well as recognition of liability on the part of the manufacturer for possible defects should you make a warranty claim. Download an official Audient user manual in which you will find instructions on how to install, use, maintain and service your product.

And do not forget – unsuitable use of a Audient product will considerably shorten its lifespan!



Product description

NAMM 2019: Audient Sono Dials-In the Ultimate Valve Guitar Audio Interface Read More azvqtuzdzyfayudzfyudzyzwvtufbfdydt Designed for electric guitarists and their accompanying bands, the Audient Sono is a 10-in/4-out USB type-C audio interface with a tube-powered front-end. It also sports a three-knob tone stack, as well as onboard amp-simulation and speaker-cab emulation from Two Notes, a renowned amp-modeling company.

With its relatively compact construction, the Sono can integrate with your pedalboard, accepting your whole effect chain through its amplifier input. Hit the Sono with your guitar and you've got options for how to proceed. You can tweak how hard you hit the tube with the Input knob, or how hard you hit the digital power-amp stage with the Drive Knob. The Output knob adjusts the output level. Adjust the tone to your liking with Bass, Mid EQ, and Treble knobs. Access multiple amps and cabs from the sound of Marshall 4x12s to sweet Fender timbres.

The Sono also allows you to route your output in a variety of ways: foresake the amplifier for DI feed straight to house. Monitor the sound with headphones for silent practicing, record over USB to the computer, or feed sound directly to an amplifier.

If you'd like to record a DI sound quickly and reamp later, the Sono can take a dry DI signal for later tweaking. Two combination XLR-1/4" inputs with Audient Console mic pres can accept mic and line-level sound sources. Combine these with ADAT inputs for eight channels from an external interface and you can record your band efficiently and effectively. Give yourself five channels for the drums,with three left over for guitars and bass. Plug in a condenser mic, switch on phantom power, send it through the tube, and you can now overdub some warm lead vocals.

A monitor mix allows for zero-latency monitoring while recording, so you never have to worry about latency problems during the tracking process. For the live player, Sono lets you store up to three presets on the unit itself via the Cab button, letting you take your exact sound with you live, and letting you leave the amplifier at home.

The Sono comes with a power adapter as well as two USB cables, so it can work with any computer.
    Key Features at a Glance
    • 10-in/4-out USB interface
    • Classic valve preamp with 12AX7 tube
    • 3-band tone control
    • Two Notes power amp and cab simulation
    • Reamp output
    • 2x Audient Console mic pres
    • High-performance AKM AD/DA converters
    • ADAT input for expandability
    • Main speaker output
    • Independent headphone output
    • Zero-latency monitoring with monitor mix
    • USB 2.0 compliant
    • 24-bit / 96 kHz
    • All-metal enclosure
    • Free plugins and software with ARC
In the Box Audient Sono USB Audio Interface For Electric Guitar Players
  • Limited 1-Year Warranty
  • Power Adapter
  • USB Type-C to USB Type-C Cable
  • USB Type-C to USB Type-A Cable
  • User Manual PDF 13.8mb Table of Contents




    Upload User Manual

    Have you got an user manual for the Audient Sono USB Audio Interface For Electric Guitar Players in electronic form? Please send it to us and help us expand our library of instruction manuals. Thank you, too, on behalf of other users.

    To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
    Upload PDF user manual Upload DOC user manual
    Please enter here the link to the user manual of this product:





    OR

    Enter here the file with the user manual of this product from your computer/phone:
    (60MB max; Permitted formats: PDF)

    0%


    Technical parameters

    Audient Sono Specs

    Channels of I/O Analog / Digital:
    10 Inputs / 4 Outputs at 96 kHz
    Max Sample Rate/Resolution 96 kHz / 24-Bit
    Host Connection 1 x USB Type-C (USB 2.0)
    Analog I/O 2 x Combo XLR / 1/4" Balanced Mic/Line Input
    1 x 1/4" (6.3 mm) Unbalanced Hi-Z Input
    1 x 1/4" (6.3 mm) Unbalanced Re-Amp Output
    1 x 1/4" (6.3 mm) Unbalanced Headphone Output
    2 x 1/4" (6.3 mm) TRS Balanced Monitor Output
    Phantom Power +48 V (Selectable on Individual Inputs)
    Digital I/O 1 x TOSLINK / ADAT (I/O) Input
    MIDI I/O None
    Gain Range Mic Inputs:
    60 dB
    Dynamic Range A/D Converters:
    114 dB
    Outputs:
    114 dB
    Headphone Out:
    114 dB
    Sample Rates Up to 96 kHz (AD/DA Conversion)
    Bit Depth Up to 24-Bit (AD/DA Conversion)
    OS Compatibility macOS 10.6 or Later
    Windows Vista
    Windows 7
    Windows 8 For Torpedo Remote Software
    Power Requirements AC/DC Power Adapter (Included)
    AC/DC Power Adapter 12 VDC at 2 A, Center-Positive (Included)
    Anti-Theft Features None
    Dimensions 8.98 x 7.36" / 22.8 x 18.7 cm
    Package Weight 4.435 lb
    Box Dimensions (LxWxH) 12.4 x 9.2 x 4.4"
