Product description Provided by third party: The AVInAir Spectre 7" Wireless FPV HD Ground Station Monitor with Dual 32-Channel Receiver is built for first-person viewing of outdoor video and audio, especially for receiving wireless streaming feeds from your RC aircraft/drone mounted camera. With a built-in Dual 32-Channel 5.8 GHz Receiver set, the line of sight is greatly improved for longer transmission distances. This monitor does not transmit blue screens, enabling you to see parts of a streaming image or video instead of a blue screen in the event of a signal loss.
The 7" LED backlit LCD display has a high resolution of 800 x 480 - with a maximum resolution of 1920 x 1440 - as well as a high contrast ratio of 5000:1 and a high brightness of 400 cd/m2. The high-resolution display allows for crisp, clear images even in sunny conditions, thanks to its anti-glare surface. The built-in analog composite AV input connects to the aerial camera, switching the pixel aspect ratio from 16:9 to 4:3 and vice versa.
- Key Features
-
- Built-in dual 32 Channel 5.8 GHz video receivers and diversity transceiver system that automatically selects the optimal video signal
- 7" LCD, LED Backlit display
- Display resolution up to 1920 x 1440 pixels
- 400 cd/m2 Brightness
- 16:9 or 4:3 adjustable display ratio
- Contrast ratio of 500:1
- Smooth video transmission with no blue screen in case of signal loss
- Supports composite video RCA input
- Multi-color format support for selecting the same format as your camera
Table of Contents
|
Upload User Manual
Have you got an user manual for the Avinair Spectre 7" Wireless FPV HD Ground Station Monitor with Dual 32-Channel Receiver in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersAvinair AV-FPV-769WDT Specs | | | Type | Wireless LCD monitor | | Width | 7.2 in | | Depth | 1.2 in | | Height | 5 in | | Weight | 12.7 oz | | | | Supported Video Signals | Composite video; NTSC, PAL, SECAM | | Audio Support | Yes | | | | Recommended Use | FPV system | | Supported Image Aspect Ratio | 16:9 | | Color Support | Color | | Display Size | 7" | | Native Resolution | 800 x 480 | | LCD Technology | TFT active matrix | | Built-in Speakers | 1 speaker | | Features | Battery operated, LED backlight, built-in dual 32-channel wireless 5.8 GHz AV receiver | | | | Max Power Consumption | 5 W | | Low Voltage Power | DC 6 - 24 V | | | | Kit Content | (1) x sun shade
(2) x wireless antenna | | | | Terminals | (1) x composite video input - RCA
(1) x audio line-in - RCA
(1) x DC power input
(2) x RF input | | | | Min Operating Temperature | -4
