User Manual for Avinair Spitfire Pro 3G-SDI to HDMI Converter Click to enlarge the picture
Contents of the user manual for the Avinair Spitfire Pro 3G-SDI to HDMI
- Product category: Signal Converters Avinair
- Brand: Avinair
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Avinair Signal Converters
|
User manual for the Avinair Spitfire Pro 3G-SDI to HDMI contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Avinair product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Avinair user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Avinair product will considerably shorten its lifespan!
|
Product description The AVInAir Spitfire Pro 3G-SDI to HDMI Converter is a robust unit that features auto signal detection and a loop through 3G-SDI output. It converts SD/HD/3G-SDI signals into full HD HDMI 1.3a signals supporting a maximum of 8-channel HDMI embedded audio outputs.
The converter supports 30/36-bit color in the RGB and YUV color space, and 24-bit audio at 48 kHz. It is built into an industrial metal case with LED indicators confirming power and video. It includes two installation brackets for mounting on the unit on a wall and an AC power adapter. UPC: 753807557252 In the Box Avinair Spitfire Pro 3G-SDI to HDMI Converter 2 x L-Type Metal Brackets for Wall Installation 5 VDC Adapter Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Avinair Spitfire Pro 3G-SDI to HDMI Converter in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersAvinair AV-SF-SH101A Specs | Interface | 3G-SDI
Input: 1 x BNC
Output: 1 x BNC (loop through)
HDMI
Input: 1 x HDMI (type A) | | Input Formats | SD/HD/3G-SDI
SMPTE-259/274/292/296/372/424/425 | | Output Formats | HDMI v1.3a
30/36 bits per pixel, RGB or YUV
1080p 23.98/24/25/29.9/30/50/59.94/60
1080i 50/59.94/60
720p 50/59.94/60
625i
525i | | Audio | Input Formats
SDI Embedded: 24 bit/48 kHz, 8 channels max
Output Formats
HDMI Embedded: 24 bit/48 kHz, 8 channels max | | Power Consumption | 1.3 W | | Temperature | Operating: 32 to 104°F; / 0 to 40°C
Storage: -4 to 140°F / -20 to 60°C | | Compliance | FCC
CE | | Dimensions | 3.2 x 2.2 x 1.2" / 82 x 55 x 30 mm | | Weight | .39 lb / .18 kg | | | | Package Weight | 0.7 lb | | Box Dimensions (LxWxH) | 6.9 x 5.0 x 1.8" |
