Product description The B+W 122mm Yellow SC 022 Filter can be used to increase image contrast when photographing using a film camera system with black-and-white film installed.
This filter's effect corresponds to that of a Wratten 8 filter. Wavelengths of visible light that are apparent as violet and blue colors to the human eye are suppressed, while visible light associated with green, yellow, orange, and red colors are able to more easily pass though the B+W 122mm Yellow SC 022 Filter and into the lens it is mounted in front of. When photographing with this filter along with black-and-white film, violet to blue-colored subjects within a scene are reproduced in darker shades of grey than without a filter. Simultaneously, green, yellow, orange, and red subjects are rendered in lighter shades of grey than if a filter was not used.
When applied to black-and-white photography, the increased contrast provided by the B+W 122mm Yellow SC 022 Filter can result in darker skies with more effectively defined clouds. Shades of green among foliage can be better differentiated, while tans are lightened, and the appearance of skin blemishes reduced. Additionally, this filter can also minimize the presence of haze caused by the bluish cast of daylight.
To prevent internal ghosting and reflections, each glass surface includes one layer of anti-reflection coating. B+W filters are constructed from Schott glass for increased optical clarity. This filter features an F-Pro brass filter ring for durability as well as jamming prevention. - Increases image contrast when photographing using a film camera system with black-and-white film installed
- Produces darker shades of grey from violet to blue-colored subjects and lighter shades of grey from green, yellow, orange, or red subjects than without a filter
- When applied to black-and-white photography, can result in darker skies with more defined clouds, better differentiated green foliage, lightened tans, reduced skin blemishes, and minimizes the presence of haze caused by the bluish cast of daylight
- 0.3 density and 2x filter factor create up to a one-stop reduction of light
- Single coated to prevent internal ghosting and reflections
- Constructed from Schott glass for optical clarity
- F-Pro brass filter ring helps to prevent jamming and provides additional strength
- Padded pouch included for storage and transport
In the Box B+W 122mm Yellow SC 022 Filter Filter Pouch Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the B W 122mm Yellow SC 022 Filter in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersB+W 65-070644 Specs | Filter Factor/Density | 0.3 (1 Stop) 2x | | Circular Size | 122 mm | | Front Accessory Thread / Bayonet | 122 mm | | Filter Material | Glass | | Grade | Equivalent to Wratten 8 | | Color Type | Black-and-White Contrast | | | | Package Weight | 0.4 lb | | Box Dimensions (LxWxH) | 9.0 x 6.5 x 1.3" |
