Product description

The B+W 72mm UV/IR Cut MRC 486M Filter is an ultraviolet and infrared control filter that is useful for digital cinematography as well as still photography. While recording video with a CCD or CMOS camera, multi-stop neutral-density filters are used to maintain proper exposure by compensating for increased light levels when widening the camera lens's iris to obtain a narrower depth of field. As the increased amount of light passes through multi-stop neutral-density filtration, visible light is progressively blocked, while infrared light is allowed to pass through. As the proportion of infrared light that reaches the sensor of a camera being used for digital cinematography becomes greater, the results can show unwanted color shifts, particularly in dark areas of the frame such as shadows where the appearance of black is dominant.

When the B+W 72mm UV/IR Cut MRC 486M Filter is applied, 88% of ultraviolet light waves are blocked at 380 nanometers along with 95% of infrared light waves at 700 nanometers, helping to ensure that light falling on a digital camera sensor is limited to the visible spectrum. When used along with multi-stop neutral-density filters while recording with a digital sensor, potential infrared color shifts are prevented or minimized, preserving color accuracy throughout the frame. This filter may also be used to help ensure that the appearance of unwanted blue casts is reduced while recording digital video or still photos under daylight that also features intense ultraviolet light.

The front surface of a B+W 72mm UV/IR Cut MRC 486M Filter includes thirty layers of interference coatings which allow it to limit the light that falls on a digital camera sensor to the visible spectrum. When combined with a wide-angle lens, lower-frequency wavelengths of visible light associated with yellow, orange, and red colors passing through the filter and along that lens type's curved edges can be impeded in a significantly greater degree than higher-frequency wavelengths of visible light associated with blue and violet colors. This can result in an unwanted cool cast along the edges of an image taken with a B+W 72mm UV/IR Cut MRC 486M Filter and a wide-angle lens. To avoid such color shifts along the edges of an image when using this filter, it is recommended not to be used with lenses that are intended to provide an angle of view greater than 60°.

Eight layers of anti-reflection coating are included on the rear glass surface of this B+W 72mm UV/IR Cut MRC 486M Filter. This Multi-Resistant Coating (MRC) prevents internal ghosting and reflections, offers protection to the filter substrate, and helps its rear surface to stay clean for longer than with uncoated filters.

B+W filters are constructed from Schott glass for increased optical clarity and color fidelity. The B+W 72mm UV/IR Cut MRC 486M Filter features an F-Pro brass filter ring for durability and jamming prevention, as well as 72mm front filter threads that allow it to be paired with other filter types. When in use, but not combined with another filter that provides a specific effect, it is recommended to place a clear, protective filter over the B+W 72mm UV/IR Cut MRC 486M Filter to prevent damage to its front interference coatings.
  • 88% of ultraviolet light waves are blocked at 380 nanometers, before which they are further removed, reducing bluish cast of daylight when recording video or still photos.
  • 95% of infrared light waves are blocked at 700 nanometers, after which they are progressively eliminated.
  • Useful with CCD or CMOS sensors to filter out infrared light pollution that cause color shifts frequently associated with high-definition recording with multi-stop neutral-density filters.
  • Does not require adjustments to exposure while in use.
  • Thirty layers of interference coatings on front surface limits light that falls on a digital camera sensor to the visible spectrum.
  • Multicoated rear surface prevents internal ghosting and reflections.
  • Constructed from Schott glass for optical clarity.
  • F-Pro brass filter ring helps to prevent jamming and provides additional strength.
  • 72mm front filter threads allow use with other filters to protect front surface or combine with other effects.
  • Plastic case for storage and transport.
In the Box B+W 72mm UV/IR Cut MRC 486M Filter
  • Filter Case
  • Limited 1-Year Warranty
  • Table of Contents




    Upload User Manual

    Have you got an user manual for the B W 72mm UV IR Cut MRC 486M Filter in electronic form? Please send it to us and help us expand our library of instruction manuals. Thank you, too, on behalf of other users.

    To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
    Upload PDF user manual Upload DOC user manual
    Please enter here the link to the user manual of this product:





    OR

    Enter here the file with the user manual of this product from your computer/phone:
    (60MB max; Permitted formats: pdf, docx, jpg)

    0%


    Technical parameters

    B+W 66-031975 Specs

    Circular Size 72 mm
    Front Accessory Thread / Bayonet 72 mm
    Filter Material Glass
    Package Weight 0.18 lb
    Box Dimensions (LxWxH) 3.7 x 3.7 x 0.8"

    Rating

    80% users recommend this product to others. And what about you?
    Rating: 4.0 of 5

    This product has already been rated by 29 owners. Add your rating and experience with the product.
