Product description The B+W Series 7 UV/IR Cut MRC 486M Filter is an ultraviolet and infrared control filter that is useful for digital cinematography as well as still photography. While recording video with a CCD or CMOS camera, multi-stop neutral-density filters are used to maintain proper exposure by compensating for increased light levels when widening the camera lens's iris to obtain a narrower depth of field. As the increased amount of light passes through multi-stop neutral-density filtration, visible light is progressively blocked, while infrared light is allowed to pass through. As the proportion of infrared light that reaches the sensor of a camera being used for digital cinematography becomes greater, the results can show unwanted color shifts, particularly in dark areas of the frame such as shadows where the appearance of black is dominant.
By blocking ultraviolet light waves up to 380 nanometers as well as infrared light waves down to 750 nanometers, the B+W UV/IR Cut MRC 486M Filter helps to limit the light that falls on a digital camera sensor to the visible spectrum. When used along with multi-stop neutral-density filters while recording with a digital sensor, potential infrared color shifts are prevented or minimized, preserving color accuracy throughout the frame. This filter may also be used to help ensure that the appearance of unwanted blue casts are reduced while recording digital video or still photos under daylight that also features intense ultraviolet light.
The front surface of a B+W Series 7 UV/IR Cut MRC 486M Filter includes thirty layers of interference coatings which allow it to limit the light that falls on a digital camera sensor to the visible spectrum. When combined with a wide-angle lens, lower-frequency wavelengths of visible light associated with yellow, orange, and red colors passing through the filter and along that lens type's curved edges can be impeded at a significantly greater degree than higher-frequency wavelengths of visible light associated with blue and violet colors. This can result in an unwanted cool cast along the edges of an image taken with a B+W Series 7 UV/IR Cut MRC 486M Filter and a wide-angle lens. To avoid such color shifts along the edges of an image when using this filter, it is recommended not to be used with lenses that are intended to provide an angle of view greater than 60°.
Eight layers of anti-reflection coating are included on the rear glass surface of this B+W Series 7 UV/IR Cut MRC 486M Filter. This Multi-Resistant Coating (MRC) prevents internal ghosting and reflections, offers protection to the filter substrate, and helps its rear surface to stay clean for longer than with uncoated filters.
B+W filters are constructed from Schott glass for increased optical clarity and color fidelity. This filter features a brass filter ring for durability as well as jamming prevention. - Blocks ultraviolet light and reduces bluish cast of daylight when recording digital video or still photos.
- Useful with CCD or CMOS sensors to filter out infrared light pollution that cause color shifts frequently associated with high-definition recording.
- Ideal for use with multi-stop neutral-density filters.
- Does not require adjustments to exposure while in use.
- Thirty layers of interference coatings on front surface limits light that falls on a digital camera sensor to the visible spectrum.
- Multi-coated rear surface prevents internal ghosting and reflections.
- Constructed from Schott glass for optical clarity.
- Brass filter ring helps to prevent jamming and provides additional strength.
- Plastic case for storage and transport.
In the Box B+W Series 7 UV/IR Cut MRC 486M Filter Filter Case Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the B W Series 7 UV IR Cut MRC 486M Filter in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersB+W 66-1070164 Specs | Filter Type | Ultraviolet and infrared control | | Size | Series 7 | | Filter Factor | 1 (0 stop) | | Effect | Reduces unwanted blue casts when used under daylight; prevents or minimizes unwanted color shifts when using multi-stop neutral density filtration with digital cinematography cameras | | Construction | Schott glass | | | | Package Weight | 0.05 lb | | Box Dimensions (LxWxH) | 2.6 x 2.6 x 0.7" |
