User Manual for Barco HDBaseT Receiver Module for Present-P Projectors Click to enlarge the picture
Contents of the user manual for the Barco HDBaseT Receiver Module for Present-P
- Product category: Projector Accessories Barco
- Brand: Barco
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Barco Projector Accessories
|
User manual for the Barco HDBaseT Receiver Module for Present-P contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Barco product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Barco user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Barco product will considerably shorten its lifespan!
|
Product description The HDBaseT Receiver Module for Present-P Projectors from Barco is a receiver module for transmitting high quality, uncompressed video signals through a single network (CAT6) cable. The module is compatible with Crestron, Extron, AMX, Gefen, Kramer and HDBaseT devices. It is a cost-efficient solution that supports resolutions up to WUXGA for a distance of up to 330'. Designed to be integrated under the hood of the Present-P projectors, the module allows you to extend your HDBaseT connectivity to devices that do not natively support it. In this way, you have the flexibility to easily add HDBaseT connectivity whenever you need it. Connect the HDBaseT module to the HDMI port on your display to enable your device. After that, you will be able to receive high quality, uncompressed video signals through a single network cable (CAT6) supporting the HDBaseT standard. Your source device can be up to 330' away. - HDMI and Ethernet extension up to 330'
- Supports resolutions Ultra HD 4K x 2K and 1080p Full HD
- Supported HDMI features
HDCP-compliant
12-bit deep color
LPCM 7.1 audio, Dolby TrueHD, Dolby Digital Plus, and DTS-HD Master Audio pass-through
3DTV pass-through
CEC pass-through
Lip Sync pass-through - Compatible with Crestron, Extron, AMX, Gefen, Kramer and HDBaseT devices
- DIP switch settings for EDID management
- Expand your connectivity to support HDBaseT
- Compact, stand-alone unit
In the Box Barco HDBaseT Receiver Module for Present-P Projectors Limited 1-Year Warranty Brochure PDF 581.6kbuvqvedtabvsfrevbuafbvaxvfz Table of Contents
|
Upload User Manual
Have you got an user manual for the Barco HDBaseT Receiver Module for Present-P Projectors in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersBarco R9801305 Specs | Range | Up to 330.0â™ (100.0 m) | | Maximum Pixel/TMDS Clock | 300 MHz | | Connector and Ports | Video Output: HDMI type A 19-pin female
Link: RJ-45 (shielded)
Ethernet: RJ-45 (shielded) | | Power Supply | 5 VDC (locking) | | Power Consumption | 10 W (maximum) | | Dimensions (W x H x D) | 3.2 x 3.4 x 1.2" (81.0 x 86.0 x 30.0 mm) |
Rating80% users recommend this product to others. And what about you?
This product has already been rated by 27 owners. Add your rating and experience with the product.
