Product description The ImagePRO-II All-in-One Video Scaler, Scan Converter, and Switcher with Dual Link and Audio Modules from Barco can convert any input signal format to any output format. The ImagePRO-II supports universal analog, DVI single and dual link, HDMI, DisplayPort, and SD/HD/3G SDI signal formats. Loop-through outputs are provided for the analog, DVI, and SDI input and genlock signals. With features such as 12-bit processing, HDCP and EDID management, USB backup and restore, multiple video effects, and a web browser interface, the ImagePRO-II is an advanced and flexible signal processing solution. This model has the Dual Link module which adds a second scaled output via an included upgrade card. The output card features three additional SDI spigots which support the input, loop, and output signals. Each output's resolution, frame rate, AOI, effects, or pan and zoom can be configured separately. Bundled with the ImagePro-II is an audio module upgrade, which adds an audio mezzanine board that gives you access to embedded audio from the video input signals. The mezzanine board features a DB-25 connector, providing an I/O interface for four analog and eight AES digital channels. You can select and use the embedded audio from the video input source signal, or from the analog or AES digital signal from the DB-25 connector. The de-embedded HDMI, DisplayPort, and SDI input audio signals can also be selected to appear on the discrete analog or digital AES outputs. Note: The ImagePRO-II Audio Breakout Cable is required to access the analog and digital AES signals from the DB-25 connector. The breakout cable provides four XLR connectors for analog audio in/out, and eight BNC connectors for Digital AES in/out. In the Box Barco ImagePRO-II All-in-One Video Scaler, Scan Converter, and Switcher with Dual Link and Audio Modules Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Barco ImagePRO-II All-in-One Video Scaler, Scan Converter, and Switcher with Dual Link and Audio Modules in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersBarco R9004668 Specs | | | DVI | 1 x DVI-I port on input 1
Digital Formats: all single-link DVI digital formats up to 165 Mhz, per DVI 1.0 Specification and all dual-link DVI formats up to 300 Mhz; Max H Active: 4096 Max V Active: 3072
Analog Formats: NTSC/PAL composite and Y/C video, SD YPbPR with bi-level sync, HD YPbPr with tri-level sync, RGBHV/RGBS/RGsB computer video with bi-level sync
Analog Sampling: sources with pixel rates up to 170 Mhz are sampled 1:1; sources with pixel rates above 170 Mhz are filtered and sampled at 170 Mhz, including but not limited to 1920x1200p, 2048x1080p
Active loop-through output of all input signals, including HDCP and EDID
EDID version 1.3 compatible HDCP version 1.4 compatible | | VGA | 1 x HD-15 VGA port on input 2
Formats: NTSC/PAL composite and Y/C video SD YPbPr with bi-level sync HD YPbPr with tri-level sync per SMPTE 274, RGBHV/RGBS/RGsB computer video with bi-level sync
Sampling: sources with pixel rates up to 170 Mhz are sampled 1:1; sources with pixel rates above 170 Mhz are filtered and sampled at 170 Mhz, including but not limited to: 1920x1200p, 2048x1080p
Active loop-through output of all input signals
EDID version 1.3 compatible | | HDMI | 1 x HDMI type A port on input 3
Formats: RGB and YCbCr; Resolutions up to 2048x1080p @ 60 Hz per HDMI 1.4 specification and 1,920 x 1,200p @ 60 Hz
EDID version 1.3 compatible
HDCP version 1.4 compatible
Deep color (30/36 bits) | | DisplayPort | 1 x DisplayPort port on input 4
Formats: resolutions up to 2560x1600 @ 60Hz (30 bits) per DisplayPort 1.1a specification
HDCP version 1.4 compatible | | SDI | 2 x BNC ports on inputs 5 and 6
Formats: SD-SDI per SMPTE 259M-C (NTSC/PAL resolution); HD-SDI per SMPTE 292M, 296M; 3G-SDI per SMPTE 424
Re-clocked loop-through output
Dual link HD-SDI per SMPTE 372 | | | | SDI | Formats: SD-SDI per SMPTE 259M-C (NTSC/PAL resolution); HD-SDI per SMPTE 292M, 296M; 3G-SDI per SMPTE 424
Dual link HD-SDI per SMPTE 372 | | Composite | Formats: NTSC, PAL
CVBS on BNC connector | | DVI | Formats: all single-link DVI digital formats up to 165 Mhz, per DVI 1.0 specification, all dual-link DVI formats up to 330 Mhz
EDID version 1.3 compatible
HDCP version 1.4 compatible | | VGA | Formats: NTSC/PAL composite on green, NTSC/PAL Y/C video with bi-level sync on Y only, (Y: Green, C: Red); SD YPbPr with bi-level sync; HD YPbPR with tri-level sync per SMPTE 274; RGBHV/RGBS/RGsB computer video with bi-level sync
EDID version 1.3 compatible | | HDMI | Formats: RGB and YCbCr at 4:4:4, YCbCr at 4:2:2, per HDMI 1.4 specification; Resolutions up to 2,048 x 1,080p @ 60Hz and 1,920 x 1,200 @ 60Hz
EDID version 1.3 compatible
HDCP version 1.4 compatible | | DisplayPort | Formats: resolutions up to 2560x1600 @ 60Hz (30 bits) per DisplayPort 1.1a
HDCP version 1.4 compatible | | | | Genlock | Analog Ref Input/Loop/Output on BNC connectors; Bi-level and Blackburst at SD and Tri-level at HD or locked to any input | | Remote Control | USB 1.1
Ethernet RJ-45, 10/100 Mbps Autosense
Computer, tablet, smartphone, or external Encore or ScreenPRO-II Controller via Ethernet link
Control functions include: source input configuration, output format selection, test pattern selection, transition effect selection and control | | Input Power | 100-240 VAC, 47-63 Hz, auto-selecting 2.0A maximum | | Environmental | 32 to 104°F / 0 to 40°C
0 to 95% humidity, noncondensing | | Dimensions | 1.75 x 17 x 18.5" / 4.4 x 43.2 x 47 cm | | Weight | 15.75 lb / 7.1 kg | | | | Package Weight | 24.85 lb | | Box Dimensions (LxWxH) | 25.5 x 25.0 x 6.13" |
