User Manual for Barska 10x42 Embark Waterproof Binocular Click to enlarge the picture
Contents of the user manual for the Barska 10x42 Embark Waterproof Binocular
- Product category: Binoculars Barska
- Brand: Barska
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Barska Binoculars
 |
User manual for the Barska 10x42 Embark Waterproof Binocular contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Barska product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Barska user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Barska product will considerably shorten its lifespan!
|
Product description The B&H Binocular Buying Guide Read More ucfusuzwrrdtsc Barska designed their 10x42 Embark Waterproof Binocular as your go-to optic for all outdoor activities. Its 10x magnification is ideal for bird watching, hiking, and sightseeing; and the larger 42mm objectives, coupled with multi-coated optics, draw in copious amounts of light versus smaller-objective optics to produce bright and clear images with competent low-light performance. Utilizing an open-bridge/dual-hinge configuration helps to cut weight without sacrificing stability while providing plenty of room to wrap your hands completely around the optical tubes for a better grip.The combination of long eye relief, wide exit pupil, and twist-up eyecups ensures comfortable use by most people with or without eyewear in all light conditions. The optical tubes are nitrogen-filled and O-ring sealed for water and fogproof performance, so you can be confident bringing them with you anywhere you go. If you plan on long-duration observation sessions, the Embark can be mounted on support systems using an optional tripod adapter. - Optical Performance
-
- Magnification: 10x
- 42mm objective lenses
- Compact BAK4 roof prisms
- Anti-reflection multi-coated optics improves light transmission, color rendition, and contrast
- Near wide-angle 56° apparent angle of view
- 294' field of view at 1000 yards
- Use and Handling
-
- Open bridge, dual-hinge configuration offers stability and rigidity while reducing weight
- Bridge design provides more gripping surface for steadier handling
- Large knurled center focus wheel
- Right-eye dioptric correction
- Twist-up eyecups for comfortable use with or without eyewear
- Tripod mountable with optional 1/4"-20 adapter
- Long 15mm eye relief
- Wide 4.2mm exit pupil
- Construction Details
-
- Protective brown rubber armoring
- Textured armoring improves grip in cold and wet conditions
- Nitrogen-filled and O-ring sealed for water and fogproof performance
- Weight: 22.4 ounces
UPC: 790272002191 In the Box Barska 10x42 Embark Waterproof Binocular (Brown) Carrying Case Neck Strap Lens Cloth Limited Lifetime Warranty Summer Binocular Buying Guide Christopher Witt 07/14/2016 ucfusuzwrrdtsc A Guide to Marine Binoculars Todd Vorenkamp 06/25/2015 Pentax Sport Optics Binocular Roundup Joseph Albanese 06/24/2015 A Guide to Birding with Binoculars Todd Vorenkamp 06/16/2015 Table of Contents
|
Upload User Manual
Have you got an user manual for the Barska 10x42 Embark Waterproof Binocular in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersBarska AB12680 Specs | Prism Type | Roof | | Magnification | 10 x | | Objective Lens Diameter | 42 mm | | Angle of View | 5.6° (Actual) | | Field of View | 294.0' @ 1000 yd / 98.0 m @ 1000 m | | Minimum Focus Distance | 6.5' / 2 m | | Exit Pupil Diameter | 4.2 mm | | Eye Relief | 15.0 mm | | Focus Type | Center | | Tripod Mount | Yes (Adapter Optional) | | Dimensions | 6.2 x 5.1 x 2.0" / 15.9 x 12.9 x 5.1 cm | | Weight | 22.4 oz / 635.0 g | | | | Package Weight | 2.1 lb | | Box Dimensions (LxWxH) | 7.9 x 6.6 x 3.3" |
Rating100% users recommend this product to others. And what about you?
