User Manual for Barska 6.5-20x50 AO Varmint Riflescope Click to enlarge the picture
Contents of the user manual for the Barska 6.5-20x50 AO Varmint Riflescope
- Product category: Riflescopes Barska
- Brand: Barska
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Barska Riflescopes
|
User manual for the Barska 6.5-20x50 AO Varmint Riflescope contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Barska product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Barska user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Barska product will considerably shorten its lifespan!
|
Product description Barska's 6.5-20x50 AO Varmint Riflescope is optimized for long-range, small targets, and varmint hunting. Its optical system features a high, 6.5-20x magnification that will bring almost any target within your reach. The wide 50mm objective aperture provides bright and clear images in most low-light conditions and at high magnifications. Other highlights of the optical system include anti-reflection, multi-coated lenses and a 2nd focal plane Target Dot reticle. The reticle is well-suited for aiming at small targets and features a fine full-field crosshair, no posts, and a bold center target dot. To offer a parallax-free aiming, the scope also provides an adjustable objective parallax corrector. To help you to compensate for ballistic drops and winds, this optic has windage and elevation adjustments with 1/8 MOA click values.
The aluminum housing offers a waterproof, fogproof, and shock-resistant performance. It features a 1" diameter maintube and capped, finger-operated windage and elevation turrets. All the rings and adjusters have knurling for a non-slip grip and easy tuning. This riflescope also includes two lens caps and a lens cloth. - Target Dot Reticle
-
- 2nd focal plane
- Bold center target dot
- Extended full-field crosshair with no posts
- Adjustable parallax from 25 yd to infinity
- Optical Performance
-
- Multiple anti-reflection coatings
- 50mm objective improves image brightness in low-light and at high magnifications
- 6.5-20x zoom magnification for precision and long range target acquisition
- Use and Handling
-
- 1/8 MOA impact point correction
- Windage and elevation adjustments
- Construction Details
-
- 1" maintube diameter
- Anodized aluminum housing
- Capped finger-operated turrets
- Adjustable objective parallax corrector
- Fogproof and waterproof
- Two lens caps included
UPC: 790272803385 In the Box Barska 6.5-20x50 AO Varmint Riflescope (Target Dot Reticle, Black Matte) - 2 x Lens Caps
- Lens Cloth
- Limited Lifetime Warranty
Table of Contents
|
Upload User Manual
Have you got an user manual for the Barska 6.5-20x50 AO Varmint Riflescope in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersBarska AC10048 Specs | | | Magnification | 6.5 to 20x | | Objective Lens Diameter | 50 mm | | Field of View | 6.5x: 16' @ 100 yd / 5.3 m @ 100 m
20x: 5.7' @ 100 yd / 1.9 m @ 100 m | | Exit Pupil Diameter | 5x: 7.7 mm
20x: 2.5 mm | | Eye Relief | 3.6" / 91 mm | | | | Reticle Type | Target Dot Reticle (Second Focal Plane) | | | | Impact Point Correction | 1/8 MOA per Click | | Parallax Correction | Yes, 25 yd / 22.9 m to Infinity | | | | Water Resistance | Waterproof | | Fogproof | Yes | | | | Maintube Diameter | 1" | | Battery | 1 x CR2032 | | Dimensions | Length: 15.9" / 40.4 cm | | Weight | 22.3 oz / 632.2 g | | | | Package Weight | 1.825 lb | | Box Dimensions (LxWxH) | 17.6 x 3.15 x 3.1" |
Rating60% users recommend this product to others. And what about you?
This product has already been rated by 09 owners. Add your rating and experience with the product.
