Product description Designed to render the most accurate color possible, the Area 48 Soft LED Fixture for Remote Phosphor Panels from BB&S is a unique LED light source that separates the phosphor, which is normally integrated into the LED, from the Area 48's array. Instead, a phosphor panel with the desired color temperature is inserted into the light's accessory channel. The benefit is a higher degree of color accuracy than that of phosphor-incorporated lights as exhibited by the Area 48's as well as a very high TLCI rating of 98 for all but the chroma panels. This version of the light ships with a chroma blue panel but there are also optional 2700K, 3200K, 4300K, 5600K, and 6500K panels as well as chroma green. The Area 48 also has a strobing mode for visual effects. Built with the professional user in mind, the Area 48 is dimmable from 3-100% locally on the fixture, or remotely via 16-bit, 4-channel DMX. The light has a low-heat output that's equivalent to a 1200W tungsten flood light while consuming only 122W which translates to low operating costs and a fast return on investment. The included 100-240 VAC power supply allows worldwide use, but optional V-mount and Gold mount battery plates offer independence from mains power, an essential feature for the location shooter. - Benefits
-
- 1200W tungsten equivalent output
- Detachable barndoors, yoke and TVMP connector
- 160W, 100-240 VAC, 50/60 Hz power supply
- Draws just 122W and weighs 10 pounds
- Optional pro batteries 14.4 VDC 10 A discharge or greater
- Optional V-mount or Gold mount plates
- Integrated DMX 512 control
- Flicker-free, silent operation, no fans
- 8-/16-bit dimming: 3-100% plus strobe built into software
- Optional Remote Phosphor media is available in Chroma Green, 2700K, 3200K, 4300K, 5600K, 6500K, Chroma Blue and 10,000K
In the Box BB&S Lighting Area 48 Soft LED Fixture for Remote Phosphor Panels (AC/DC) Detachable Barndoors TVMP Bale Block Combo Baby-Junior Adapter Power Supply for Area 48 LED Panel (160W) Interchangeable Chroma Blue Phosphor Panel for Area 48 LED Light Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the BB&S Lighting Area 48 Soft LED Fixture for Remote Phosphor Panels in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersBB&S Lighting Area 48 Specs | | | Beam Angle | 160° | | Color Temperature | 2700K
3200K
4300K
5600K
6500K
10,000K Color Temperatures for Interchangeable Phosphor Panels - Chroma Green and Chroma Blu also available | | Color Accuracy Standard | TLCI 98 at 2700K
TLCI 98 at 3200K
TLCI 98 at 4300K
TLCI 98 at 5600K
TLCI 98 at 6500K | | Cooling System | Passive | | Dimming | Yes, 3 to 100% | | Display | None | | Photometrics | 160° at 5600K:
36 fc / 387.4 lux at 10' / 3.05 m
160° at 3200K:
34 fc / 365.8 lux at 10' / 3.05 m | | Expected Lamp Life | 50,000 Hours | | Fixture Dimensions | 13.9 x 10.8 x 4.5" / 353.1 x 274.3 x 114.3 mm | | Fixture Weight | 10 lb / 4.54 kg (Including Yoke) | | | | Yoke Mount | TVMP/ Hex Bolt | | Fixture Mount | 5/8" Receiver | | Accessory Mount | None | | | | Remote Control Type | DMX | | Number of DMX Channel Modes | 4 | | | | AC Input Power | 100 to 240 VAC, 50 / 60 Hz | | DC Input Power | 12 to 20 VDC | | Power Source | AC Adapter, External Battery | | Max Power Consumption | 122 W | | | | Operating Temperature | 32 to 104°F / 0 to 40°C | | | | Package Weight | 13.36 lb | | Box Dimensions (LxWxH) | 17.2 x 14.3 x 8.7" |
