Product description Designed to render the most accurate color possible, the Area 48 Studio LED Fixture for Remote Phosphor Panels from BB&S is a unique LED light source that separates the phosphor, which is normally integrated into the LED, from the Area 48's array. Instead, a phosphor panel with the desired color temperature is inserted into the light's accessory channel. The benefit is a higher degree of color accuracy than that of phosphor-incorporated lights as exhibited by the Area 48's well as a very high TLCI rating of 98 for all but the chroma panels. This version of the light ships with a chroma blue panel but there are also optional 2700K, 3200K, 4300K, 5600K, and 6500K panels as well as chroma green. The Area 48 also has a strobing mode for visual effects. Built with the professional user in in the studio in mind (hence the name), the Area 48 Studio has a 48V power supply that accepts 100-240 VAC current and is more stable than the standard 10-20V version, allowing 0-100% dimming locally on the fixture, or remotely via 16-bit, 4-channel DMX. The light has a low-heat output that's equivalent to a 1200W tungsten flood light while consuming only 122W which translates to low operating costs and a fast return on investment. - Benefits
-
- 1200W tungsten equivalent output
- Detachable barndoors, yoke, and TVMP connector
- 160W, 100-240 VAC, 50/60 Hz, 48 VDC power supply allows 0-100% dimming
- Draws just 122W and weighs 10 pounds
- Integrated DMX 512 control
- Flicker-free, silent operation, no fans
- 8-/16-bit dimming plus strobe built into software
- Optional Remote Phosphor media is available in Chroma Green, 2700K, 3200K, 4300K, 5600K, 6500K, Chroma Blue, and 10,000K
In the Box BB&S Lighting Area 48 Studio LED Fixture for Remote Phosphor Panels (AC) Detachable Barndoors Built-In 48 VDC Power Supply TVMP Bale Block Combo Baby-Junior Adapter Interchangeable Chroma Blue Phosphor Panel for Area 48 LED Light Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the BB&S Lighting Area 48 Studio LED Fixture for Remote Phosphor Panels in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersBB&S Lighting Area 48 Specs | | | Beam Angle | 160° | | Color Temperature | 2700K
3200K
4300K
5600K
6500K
10,000K Color Temperatures for Interchangeable Phosphor Panels - Chroma Green and Chroma Blue also available | | Color Accuracy Standard | TLCI 98 at 2700K
TLCI 98 at 3200K
TLCI 98 at 4300K
TLCI 98 at 5600K
TLCI 98 at 6500K | | Cooling System | Passive | | Dimming | Yes, 0 to 100% | | Display | None | | Photometrics | 160° at 5600K:
36 fc / 387.4 lux at 10' / 3.05 m
160° at 3200K:
34 fc / 365.8 lux at 10' / 3.05 m | | Number of LEDs | 48 | | Expected Lamp Life | 50,000 Hours | | Fixture Dimensions | 13.9 x 10.8 x 4.5" / 353.1 x 274.3 x 114.3 mm | | Fixture Weight | 10 lb / 4.54 kg (Including Yoke) | | | | Yoke Mount | TVMP/ Hex Bolt | | Fixture Mount | 5/8" Receiver | | Accessory Mount | None | | | | Remote Control Type | DMX | | Number of DMX Channel Modes | 4 | | | | AC Input Power | 100 to 240 VAC, 50 / 60 Hz | | DC Input Power | 48 VDC | | Power Source | AC Adapter | | Max Power Consumption | 122 W | | | | Operating Temperature | 32 to 104°F / 0 to 40°C |
