Product description Characterized by its convenient cylindrical shape, this 4'-long Pipeline Free LED Light from BB&S Lighting is a remote phosphor, 5600K-balanced fixture offering with a high TLCI of 98+ for accurate color rendering. Its 180° beam spread makes it an ideal soft light for broad and even coverage, and, despite its slim form factor, can output 4000 lumens while drawing 40W of power. An inline dimmer is connected to the light via a 10' cable and allows for 100-0% dimming adjustment without flickering or color shifting. The Pipeline is delivered with a 100-240 VAC power supply, along with international plugs and also supports 14 VDC power via an optional battery. - This 4'-long fixture outputs 4000 lumens with a 40W power draw.
- Remote phosphor 5600K-balanced fixture has a TLCI of 98+.
- Can be installed in optional single- or multi-lamp reflector banks, and can also be used in conjunction with other Pipelines of different color temperatures to achieve mid-range color temperatures.
- Heatless and silent fan-less operation.
UPC: 650135020154 In the Box BB&S Lighting Pipeline Free LED Light (4', 5600K) 3/8" Thread Pipemount with Spigot for Pipeline Power Supply for Pipeline yfauxvbxcbvuyzsbazwactcq Limited 2-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the BB&S Lighting Pipeline Free LED Light in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersBB&S Lighting Pipeline Free Specs | | | Beam Angle | 180° | | Color Temperature | 5600K | | Color Accuracy Standard | TLCI 98 | | Dimming | Yes, 0 to 100% | | Lumens | 4000 | | Expected Lamp Life | 50000 Hours | | Rectangular Panel Size | 48 x 1" / 121.92 x 2.54 cm | | | | Battery Plate | None | | Power Input Connector | Proprietary | | DMX Connector | None | | | | Fixture Mount | None | | Mount via Included Adapter | 3/8"-16 Female Thread | | | | AC Input Power | 100 to 240 VAC, 50 / 60 Hz | | DC Input Power | 14 VDC | | Power Source | AC Adapter, External Battery | | Max Power Consumption | 40 W | | | | Operating Temperature | 14 to 104°F / -10 to 40°C | | | | Package Weight | 5.25 lb | | Box Dimensions (LxWxH) | 52.5 x 6.75 x 6.5" |
