Product description The blue 2412 Multi-Conductor - Enhanced Category 6 Nonbonded-Pair Cable from Belden is a 23 AWG Solid Bare Copper Conductor insulated with polyolefin. It is made up of a PVC (Polyvinyl Chloride) outer jacket and separated internally by dielectric tape. It has a ripcord, which is situated under the jacket of the cable. The cable is suitable for applications such as premises horizontal cable, Gigabit Ethernet, 100BaseTX, 100BaseVG ANYLAN, 155ATM, 622ATM. - The Cat 6 Cable is made up of a polyvinyl chloride outer jacket and separated internally by dielectric tape.
- It is compatible with premises horizontal cable, Gigabit Ethernet, 100 Base TX, 100 Base VG, 155 ATM, 622 ATM and any LAN.
UPC: 612825061199 Table of Contents
|
Upload User Manual
Have you got an user manual for the Belden 2412 Multi-Conductor - Enhanced Category 6 Nonbonded-Pair Cable in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersBelden 24120101000 Specs | Pairs | 4 | | AWG | 23 | | Stranding | Solid | | Conductor Material | Bare copper | | Compatibility | Premises horizontal cable, Gigabit Ethernet, 100BaseTX, 100BaseVG ANYLAN, 155ATM, 622ATM | | Insulation Material | Polyolefin | | Outer Shield Material | Unshielded | | Outer Jacket Material | Polyvinyl Chloride | | Outer Jacket Diameter | 0.22" (0.56 cm) nominal | | Outer Jacket Ripcord | Yes | | Overall Cabling Separator Material | Dielectric tape | | Overall Nominal Diameter | 0.22" (0.56 cm) | | Pair Color Code Chart | - White/blue stripe and blue
- White/orange stripe and orange
- White/green stripe and green
- White/brown stripe and brown
| | NEC/(UL) Specification | CMR | | CEC/C(UL) Specification | CMR | | Other Standards | ISO/IEC 11801 ed 2.1 (2008) Class E | | EU CE Mark | Yes | | EU Directive 2000/53/EC (ELV) | Yes | | EU Directive 2002/95/EC (RoHS) | Yes | | EU RoHS Compliance Date | 01/01/2004 | | EU Directive 2002/96/EC (WEEE) | Yes | | EU Directive 2003/11/EC (BFR) | Yes | | CA Prop 65 (CJ for Wire and Cable) | Yes | | MII Order #39 (China RoHS) | Yes | | Telecommunications Standards | Category 6 - TIA 568.C.2 | | Other Specification | Third party verified to Category 6 | | Country Patent | US 6570095
US 6998537
US 7179999
US 7977575 | | Flame Test | UL1666 Vertical riser | | C(UL) Flame Test | FT4 | | CSA Flame Test | FT4 | | Plenum | No | | Plenum Number | 2413 | | Nominal Mutual Capacitance | 17.000 capacitance (pF/ft) | | Maximum Capacitance Unbalance | 330 (pF/100 m) | | Nominal Velocity of Propagation | 70 VP (%) | | Maximum Delay | 537 @ 100 MHz delay (ns/100 m) | | Max. Delay Skew | 45 delay skew (ns/100 m) | | Max Conductor DC Resistance | 8.2 DCR @ 68°F (20°C) (Ohm/100 m) | | Max. Operating Voltage - UL | 300 V RMS | | Maximum DCR Unbalanced | 5 DCR unbalance @ 68°F (20°C) (%) | | Storage Temperature Range | 68 to 167°F (-20 to 75°C) | | Installation Temperature Range | 41 to 122°F (5 to 50°C) | | Operating Temperature Range | 32 to 167°F (0 to 75°C) | | Max Recommended Pulling Tension | 40 lb (18.14 kg) | | Min. Bend Radius/Minor Axis | 1" (2.54 cm) | | Weight | 24 lbs (10.9 kg) | | | | Package Weight | 25.1 lb | | Box Dimensions (LxWxH) | 13.9 x 13.0 x 11.9" |
