Product description Bering Optics' D-950 Elite 1x 3rd-Gen Night Vision Riflescope Clip-On is a versatile and robust enhancement for a day riflescope. It features a 3rd-generation filmless autogated intensifier tube with a resolution of 64-72 lp/mm and a manual gain. The filmless microchannel plate generates less noise and offers greater sensitivity and higher gain. The gain control of this tube type is a manual one, which allows operators to have full control of the trade-off between amount of detail and image brightness.
The optical system offers High-Definition (HD) multi-coated lenses that deliver improved detail, resolution, and image clarity and brightness. The 78mm, f/1.5 objective lens offers a wide enough aperture for collecting light at night and enhancing visibility. To enable operation in nearly complete darkness, providing additional illumination for your targets, this night vision device can be used with an optional infrared illuminator.
The polymer housing is lightweight, impact resistant, waterproof, fogproof, and dust-resistant. To provide a solid attachment to your day riflescope's objective, this NVD offers an integrated mount with polymer inserts. As an alternative attachment to your firearm, or for connecting accessories, this device has a built-in Weaver-style rail. Also included is a carrying pouch with a strap, a protective lens cap, and one CR-123 battery. - Image Intensifier Features
-
- 3rd generation
- 64-72 lp/mm resolution
- Manual gain control allows adjusting brightness or detail
- Autogating allows operation in varying light conditions and extends the tube's life
- Filmless microchannel plate improves signal-to-noise ratio
- Optical Performance
-
- 1x magnification
- High-Definition (HD) optical glass offers greater image detail and clarity
- Multiple anti-reflection coatings improve transmission and resolution
- 78mm, f/1.5 lens system
- 33' minimum focus distance
- Construction Details
-
- Impact-resistant polymer housing
- Built-in Picatinny/Weaver rail
- Mounts to 24-60mm day scope objectives
- Can be used as a scope with optional 2x eyepiece
- Flip-up objective cap
- Waterproof and fogproof
In the Box Bering Optics D-950 Elite 1x 3rd-Gen Night Vision Riflescope Clip-On (Filmless Tube, Matte Black) - Protective Carry Pouch
- Flip-Up Objective Lens Cap
- CR123 Battery
- Lens Tissue
- Limited 3-Year Warranty
Table of Contents
|
Upload User Manual
Have you got an user manual for the Bering Optics D-950 Elite 1x 3rd-Gen Night Vision Riflescope Clip-On in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersBering Optics D-950 Elite Specs | Reticle | Red-yellow Mil-Dot
Adjustable brightness | | Intensifier Tube | 3rd generation intensifier tube
Filmless microchannel plate
Autogated supply
Manual gain | | Resolution | 64-72 lp/mm | | SNR | 1:27 | | Magnification | 1x | | Linear Field of View | 39' at 100 yd / 13 m at 100 m | | Exit Pupil | 34 mm | | Lens System | 78mm, f/1.5 | | Minimum Focus Distance | 33.0' / 10.0 m | | Battery / Runtime | 1 x CR123 battery / 60 hours | | Operating Temperature | -40 to 122°F / -40 to 50°C | | Waterproofing | Waterproof and fogproof, rated IP67
Humidity: Up to 98% | | Dimensions | 8.5 x 2.6 x 3.2" / 21.5 x 6.7 x 8.1 cm | | Weight | 27.0 oz / 765.0 g |
