User Manual for Bigblue AL2600XWP Photo and Video Dive Light Click to enlarge the picture
Contents of the user manual for the Bigblue AL2600XWP Photo and Video Dive
- Product category: Continuous Lights Bigblue
- Brand: Bigblue
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Bigblue Continuous Lights
|
User manual for the Bigblue AL2600XWP Photo and Video Dive contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Bigblue product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Bigblue user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Bigblue product will considerably shorten its lifespan!
|
Product description Illuminate the wonders of the underwater world at depths as great as 328' with Bigblue's AL2600XWP Photo and Video Dive Light. Its four XML LEDs emit up to 2600 lumens in four selectable levels. The supplied, rechargeable lithium-ion battery provides a run time of 2-20 hours depending on brightness. Its 120° coverage angle lights the area before you as a photo/video light or a general dive light. A daylight-balanced 6500K color temperature helps restore hues that get absorbed by water--so you can bring color accuracy and richness back to your images. Built for durability, especially resistance to corrosion, the light has a housing constructed from anodized aluminum and an emitter window made of tempered optical glass. A push-button switch enables you to power the light on or off and cycle through output levels, while a battery indicator shows the remaining power level. - Light Performance
-
- Light source: 4 white XML LEDs, two red XPE LEDs
- Four outputs: 260, 650, 1300, and 2600 lumens
- Run time: 2 hours at 2600 lumens (level IV), 4 hours at 1300 lumens (level III), 8 hours at 650 lumens (level II), and 20 hours at 260 lumens (level I)
- Supplied, rechargeable lithium-ion battery
- Beam angle: 120°
- Daylight-balanced 6500K color temperature helps restore hues that get absorbed by water
- Switching System
-
- Push-button switch for activating power on/off functions and cycling through output modes
- Battery indicator lets you keep an eye on power level
- Construction Details
-
- Depth rating: 328'
- Anodized aluminum housing for resistance to corrosion
- Tempered optical glass emitter window
- Double O-ring seal
In the Box Bigblue AL2600XWP Photo and Video Dive Light Lithium-Ion Battery Cell 26650 for AL1800XWP Dive Light (3.7V, 4000mAh) Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Bigblue AL2600XWP Photo and Video Dive Light in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersBigblue AL2600XWP Specs | Light Source | 4 x white XML LED
2 x red XPE LED | | Depth Rating | 328' / 100 m | | Light Intensity | Level I: 260 Lumens
Level II: 650 Lumens
Level III: 1300 Lumens
Level IV: 2600 Lumens | | Beam Angle | 120° | | Color Temperature | 6500K | | Run Time | Level I: 20 hours
Level II: 8 hours
Level III: 4 hours
Level IV: 2 hours | | Switching System | Push-button with battery indicator | | Material of Construction | Housing: Anodized aluminum
Emitter Window: Tempered optical glass | | Power | Rechargeable 18650 lithium-ion battery and charger (included) | | Dimensions | Diameter x Length: 1.5 x 5.0" / 3.9 x 12.8 cm | | Weight | Underwater: -4.0 oz / -112 g including battery
Out of Water: 7.9 oz / 223 g including battery |
