User Manual for Black Box ACS4001A-R2 ServSwitch KVM over CATx Dual-Access Extender Kit Click to enlarge the picture
Contents of the user manual for the Black Box ACS4001A-R2 ServSwitch KVM over
- Product category: KVM Extenders Black Box
- Brand: Black Box
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Black Box KVM Extenders
|
User manual for the Black Box ACS4001A-R2 ServSwitch KVM over contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Black Box product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Black Box user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Black Box product will considerably shorten its lifespan!
|
Product description The ACS4001A-R2 ServSwitch KVM (DVI/USB) over CATx Dual-Access Extender Kit by Black Box, comprised of a local transmitter unit and a remote receiver unit, enables you to access your CPU from either a local or a remote USB keyboard, DVI monitor, and USB mouse. CATx cable (either CAT5, CAT5e, or CAT6) is used to extend the distance from your PC up to 400'. With this extender, you get video resolution of up to 1920 x 1200. The local unit is connected directly to the CPU and the remote KVM console with DVI-D monitor is attached to the remote unit. A local KVM console with DVI-D monitor may be attached to the local unit. This method of dual access enables you to use your computer at either location. - Extends USB keyboard, USB mouse, and DVI-D video signals up to 400' over CAT5/5e/6 cable
- Resolution up to 1920 x 1200
- Dual access feature enables you to use your computer at either location
UPC: 822088065333 In the Box Black Box ACS4001A-R2 ServSwitch KVM (DVI/USB) over CATx Dual-Access Extender Kit Limited 2-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Black Box ACS4001A-R2 ServSwitch KVM over CATx Dual-Access Extender Kit in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersBlack Box ACS4001A-R2 Specs | Color Depth | 18/21 bit | | Transmission Range | 24 AWG: 400' (121.9 m)
26 or 28 AWG: 200' (60.9 m) | | Resolution | 1920 x 1200 at 60 Hz | | Operating Temperature | 41 to 113°F (5 to 45°C) | | Humidity Tolerance | Up to 80% noncondensing | | Certification | CE | | Connectors | Local Unit:
1 x USB type B female, keyboard and mouse
1 x DVI-D female, monitor input
1 x DVI-D female, monitor output
1 x RJ-45 interconnect
1 x 5 VDC power plug
Remote Unit:
1 x USB type A female, keyboard
1 x USB type A female, mouse
1 x DVI-D female, monitor output
1 x RJ-45 interconnect
1 x 5 VDC power plug | | Power | 90 - 240 VAC, 47 - 63 Hz, autosensing, external with IEC 320 connector and cord | | Dimensions (H x W x D) | Each Unit:
1.1 x 4 x 5.6" (2.8 x 10.2 x 14.2 cm) | | Weight | Each Unit:
1.3 lb (0.6 kg) | | | | Package Weight | 3.687 lb | | Box Dimensions (LxWxH) | 10.7 x 8.2 x 4.5" |
