User Manual for Black Box ACU4001A ServSwitch Micro KVM over CATx Single-Access Extender Kit Click to enlarge the picture
Contents of the user manual for the Black Box ACU4001A ServSwitch Micro KVM
- Product category: KVM Extenders Black Box
- Brand: Black Box
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Black Box KVM Extenders
|
User manual for the Black Box ACU4001A ServSwitch Micro KVM contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Black Box product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Black Box user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Black Box product will considerably shorten its lifespan!
|
Product description The ACU4001A ServSwitch Micro KVM (VGA/USB) over CATx Single-Access Extender Kit by Black Box, comprised of a local transmitter unit and a remote receiver unit, enables you to place a VGA monitor, a USB keyboard, and a USB mouse up to 164' from your PC's CPU or USB hub, using a CATx cable (CAT5 or higher). Video resolution goes up to 1600 x 1200. The local unit is connected directly to a PC's CPU or USB port using the included extension cable, and the remote monitor, keyboard & mouse are attached to the remote unit. A local VGA monitor can be connected to the local unit.
The local unit features DDC (Display Data Channel) on all video channels, which allows it to emulate universal monitors and ensure compatibility with multi-head graphics cards. For non-standard resolutions, you can choose the monitor through the operating system and set the unit to ignore DDC. Power is supplied to the local unit through the USB interface. An optional 5V power supply may be used for video applications or when USB power is insufficient to operate the unit. The remote unit draws its power from the included power supply. If either the local or remote units are connected to a power supply that creates an over-voltage (> 5V), external surge protection prevents the units from operating.
The functionality of the ACU4001A extender may be expanded by adding external USB hubs. However, note that the use of external USB hubs may decrease the extension distance by 30' for each additional hub because of the delay imposed by each new device. Solid-core, STP/FTP cables are recommended for use with this extender. Although stranded UTP will work, transmission quality drops significantly over longer distances and in electrically noisy environments. To ensure data integrity, minimize the number of patch panels used with these devices and keep patch cable lengths less than 16.4'. - Place your USB keyboard, VGA monitor, and USB mouse up to 164' from your CPU or USB port
- Local unit supports connection of local VGA monitor
- Capable of 1600 x 1200 resolution
- Uses a single CATx (CAT5 or higher) cable
- Transparent USB 1.1 extension
- Surge protection on RJ-45 ports
- Small footprint and rackmount options
In the Box Black Box ACU4001A ServSwitch Micro KVM (VGA/USB) over CATx Single-Access Extender Kit Remote Power Supply with IEC Power Cord 3.3' USB/Video Combination Cable Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Black Box ACU4001A ServSwitch Micro KVM over CATx Single-Access Extender Kit in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersBlack Box ACU4001A Specs | Video Compatibility | Analog VGA to UXGA, RGB separate or composite video sync
Video I/O Level: 0.7 VDC pp | | USB Compatibility | Transparent USB 1.1 | | Transmission Range | 164' (50 m) Please note that some USB devices may operate at up to 196.8' (60 m) and others may only operate at up to 147.6' (45 m), depending on USB equipment and configuration | | Resolution | 1600 x 1200 @ 75 Hz, maximum | | Connectors | Local Unit:
1 x 15-pin Sub-D female, video output
1 x 15-pin Sub-D male, video input
1 x USB type B female
1 x RJ-45, interconnect
1 x barrel power plug
Remote Unit:
1 x 15-pin Sub-D female, video output
4 x USB type A female
1 x RJ-45, interconnect
1 x barrel power plug | | Power | Local Unit:
Via USB interface or optional external 5 VDC power supply (PSU1006E)
Remote Unit:
External power supply (included), 100 - 240 VAC, 50 - 60 Hz | | Dimensions (H x W x D) | Local Unit: 1.1 x 4.7 x 4.3" (2.8 x 11.9 x 10.9 cm)
Remote Unit: 1.1 x 5.4 x 3.9" (2.8 x 13.7 x 9.9 cm) | | | | Package Weight | 3.05 lb | | Box Dimensions (LxWxH) | 9.4 x 6.2 x 3.6" |
