Product description The AVSC-VGA-HDMI-R2 VGA to HDMI Scaler from Black Box converts analog PC video (VGA) with digital audio (S/PDIF) or analog stereo audio to digital HDMI. With this module, VGA-based devices such as PCs with S/PDIF or analog stereo audio can readily connect to your HDMI TV. - Supports auto-detection of resolution
- Features locking HDMI connector
- Locking power or optional USB power
- Includes an IR remote control
- Remote control via mini-USB
- Maximum pixel rate of 165 MHz
- Supports noise reduction and video enhancement features
- Over/under scanning adjustable
- Supports video H/V mirroring
- Supports active video area adjustment
- USB firmware upgradable for expanding compatibility
- Wall mount housing design for easy installation
In the Box Black Box AVSC-VGA-HDMI-R2 VGA to HDMI Scaler 5 VDC, 2A Power Supply Unit IR Remote Control Software CD Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Black Box AVSC-VGA-HDMI-R2 VGA to HDMI Scaler in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersBlack Box AVSC-VGA-HDMI-R2 Specs | Video Input | VGA | | Video Output | HDMI | | Audio Input | Digital (S/PDIF)
Analog stereo | | Audio Output | Embedded HDMI | | Audio Support | Stereo PCM (48 kHz only), digital S/PDIF | | Frequency Bandwidth | Input: 165 MHz
Output: 165 MHz | | Connectors | Input:
1 x VGA
1 x S/PDIF
1 x 3.5 mm stereo
Output:
1 x HDMI
Control and Power: 1 x USB mini B | | Indicators | 1 x Red LED (power)
1 x Green LED (video signal) | | Firmware Updates | via USB port | | Approvals | CE, FCC | | Enclosure | Metal wall mounting case with screws | | ESD Protection | Human Body Model:
±19 kV (air-gap discharge)
±12 kV (contact discharge)
Core Chipset: ±2 kV | | Operating Temperature | 32 to 104°F (0 to 40°C) | | Storage Temperature | -4 to 140°F (-20 to 60°C) | | Relative Humidity | 20 to 90%, non-condensing | | Power | Supply: 5 VDC, 2 A
Consumption: 5 W maximum | | Dimensions | 1.1 x 3.6 x 3.3" (2.8 x 9.2 x 8.3 cm) | | Weight | 9 oz (260 g) | | | | Package Weight | 2.0 lb | | Box Dimensions (LxWxH) | 7.953 x 5.591 x 3.15" |
