Product description The Broadcast Videohub from Blackmagic is a routing switcher that allows you to connect all your video equipment to a single device and then easily change connection configurations from your computer's desktop. It offers (72) inputs, (144) outputs, (72) deck control ports, and audio switching SD, HD, and 3Gbs SDI in a single unit.
Built-in rack ears make for easy placement in a standard 19" equipment rack. The unit also features (2) power supplies, the second of which serves as a redundant power source. - Broadcast Videohub
- Use this device to connect all your video equipment to a single device and then easily change connection configurations from your computer.
- Power
- Two power supplies are included with the unit, the second of which offers a redundant power source.
- Rackmount
- Its built-in rack ears make it easy to mount in a standard 19" equipment rack.
In the Box Blackmagic Design Broadcast Videohub Hub 2 x Universal Power Supplies Three-Year Warranty Against Defects in Material & Workmanship Table of Contents
|
Upload User Manual
Have you got an user manual for the Blackmagic Design Broadcast Videohub in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersBlackmagic Design VHUB/BR Specs | Input | (72) 10-bit SD-SDI, HD-SDI, 3Gbs HD & 2K switchable | | Output | (144) 10-bit SD-SDI, HD-SDI, 3Gbs HD & 2K switchable | | Control | Device Control:
(72) bidirectional Sony compatible RS-422 deck control ports
Serial ports TxRx pin reversible under software control
Router Control:
USB 2.0 high-speed interface shared over IP network | | Power | Not specified by manufacturer | | Dimensions (HxWxD) | Not specified by manufacturer | | Weight | Not specified by manufacturer | | | | Package Weight | 25.3 lb | | Box Dimensions (LxWxH) | 23.0 x 20.0 x 6.5" |
