User Manual for Blackstar Artist 15 - 5W 1x12 Tube Combo Amplifier Click to enlarge the picture
Contents of the user manual for the Blackstar Artist 15 - 5W 1x12
- Product category: Guitar Amplifiers Blackstar
- Brand: Blackstar
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Blackstar Guitar Amplifiers
 |
User manual for the Blackstar Artist 15 - 5W 1x12 contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Blackstar product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Blackstar user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Blackstar product will considerably shorten its lifespan!
|
Product description Designed for electric guitarists with discerning tonal tastes, the Blackstar Artist 15 is 15W tube combo amplifier with two channels, either of which can be set for clean or overdriven timbres. This version of the amplifier has been styled in a black finish.
Its particular tube compliment allows the amplifier to retain the dynamic range typical of American 6L6 designs, while its class-A amplifier lends the aural qualities of classic British style amplifiers. In this manner, the amplifier gives you much in the way of tonal versatility. It also boasts a built-in 12" Celestion V-Type speaker to further enhance your sound.Channel 1 includes volume and tone controls, while channel 2 provides knobs for gain and volume. For equalization, you get a classic tone stack with bass, middle, and treble, but also an addition unique to Blackstar—the ISF knob, which has been designed to help you fine tune your desired tone. Reverb level and master volume knobs round out the controls.With three speaker outputs and one emulated speaker output, possibilities for extending and routing your sound abound. A serial effects loop is also provided, complete with a pad that is switchable between +4 and -10 dB, to better suit many different types of output gear. A footswitch input jack is also provided to connect the included FS-4 footswitch, which enables you to toggle between the two channels. - Features at a Glance
-
- 2x ECC83 preamp tubes and 2x 6L6 power tubes
- Class-A amplifier circuitry
- 2 channels, clean or overdrive on each channel
- Effects loop connection with +4 / -10 dBV pad
- Classic American and British amplifier sounds
- 3 Speaker outputs for 8- or 16-Ohm loads
- Emulated speaker output
- FS-4 channel-switching footswitch included
In the Box Blackstar Artist 15 - 5W 1x12 Tube Combo Amplifier (Black) FS-4 Footswitch Limited 3-Year Warranty on Parts & Labor Limited 1-Year Warranty on Speakers Limited 90-Day Warranty on Pedals, Accessories, Tubes & Fuses Table of Contents
|
Upload User Manual
Have you got an user manual for the Blackstar Artist 15 - 5W 1x12 Tube Combo Amplifier in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersBlackstar ARTIST15 Specs | | | Amplifier Type | Tube | | Output Power | 15 W RMS | | Channels | 2 | | Tube Types | 2 x Preamp 12AX7/ECC83
2 x Power 6L6 | | Output Impedance | 8/16 Ohms Mono | | Effects Loop | Yes, Series | | Built-In Effects | Digital Reverb | | Master Volume | Yes | | Inputs | 1 x 1/4" Mono Instrument
1 x 1/4" Mono Footswitch
1 x 1/4" Mono Effects Return | | Outputs | 3 x 1/4" Mono External Speaker
1 x 1/4" Mono Emulated Speaker
1 x 1/4" Mono Effects Send | | Tone Section | Channel 1: Bass, Channel Volume, Mid, Tone, Treble
Channel 2: Bass, Channel Volume, Gain, Mid, Treble | | | | Configuration | 1 x 12" Speaker(s) | | Cabinet Type | Straight Half-Open Mono | | Power Rating | 15 W RMS | | Construction Material | Birch | | | | Dimensions (WxHxD) | 24.1 x 19.3 x 10.2" / 612.0 x 489.0 x 258.0 mm Combo | | Weight | 39.68 lb / 18 kg Combo |
Rating100% users recommend this product to others. And what about you?
This product has already been rated by 74 owners. Add your rating and experience with the product.
