User Manual for Bogen Communications A12 2-Way Wall Speaker Click to enlarge the picture
Contents of the user manual for the Bogen Communications A12 2-Way Wall Speaker
- Product category: Installed Speakers Bogen Communications
- Brand: Bogen Communications
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Bogen Communications Installed Speakers
|
User manual for the Bogen Communications A12 2-Way Wall Speaker contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Bogen Communications product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Bogen Communications user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Bogen Communications product will considerably shorten its lifespan!
|
Product description The A12 2-Way Wall Speaker from Bogen Communications is a compact high-output, long-throw loudspeaker that projects well in open spaces like theme parks, sports fields, and plazas. Two 6.5" mid/bass drivers employing both MDT and patented MLS technologies for superior sound and weather resistance deliver precise sound reproduction. The high-frequency driver is a 1.9" horn-loaded diaphragm (1" exit). A built-in 128W transformer makes the A12 compatible with 70V sound systems. The transformer can be easily bypassed for use in low-impedance systems (16 ohms). Patented spiderless technology (MLS) and advanced materials deliver dependable performance year after year. Speaker diaphragms are manufactured with materials that are not affected by exposure to UV rays, water, cold, heat, or extremely high or low humidity. - High-powered, all-weather speaker
- One model for both 70V and low-impedance systems
- 70V power settings: 128, 64, 32, 16, 8 watts
- Dual 6.5" metal-alloy MDT™ mid/bass speaker cones are extremely stable in all environments
- Patented MLS Ferrofluid voice coil suspension replaces distortion-causing mechanical spider
- Horn-loaded, 1" exit compression driver features a 1.9" Mylar diaphragm for consistent long-term performance
- 90° Horn delivers constant coverage over listening area
- Dual-layer voice coil with separate inner and outer windings for high output and ultra-low distortion
- Advanced polymer compound surrounds resist UV rays, chemicals, and salt spray
- Gold-plated, rust-proof input connectors
- High-density, injection-molded cabinet resists chipping and scratching
- Low-resonance cabinet structure
- Specially designed vent covers help keep water out
- Heavy-gauge stainless steel mounting yoke with 180° swivel
- Easy-to-grip, oversized mounting knobs
- Speaker mounts with knobs attached for easier, safer installation in hard-to-reach locations
- Corrosion-resistant woofer frames and mounting hardware for long-lasting, like-new appearance
- Black cabinet color, attractive styling using patented Armadillo ridges that improve durability as well as sound
UPC: 765368100259 In the Box Bogen Communications A12 2-Way Wall Speaker Color-Matched, Stainless Steel Mounting Bracket 5-Year Limited Warranty Guides & Manuals Table of Contents
|
Upload User Manual
Have you got an user manual for the Bogen Communications A12 2-Way Wall Speaker in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Download User ManualThe user manual for the Bogen Communications A12 2-Way Wall Speaker can be downloaded in PDF format at the link stated below.
Technical parametersBogen Communications A12 Specs | Frequency Response | 55 Hz to 17.5 kHz | | Woofer | Dual Metal-Composite 6.5" Cone Woofers, Patented MLS Voice Coil Guidance System | | Tweeter | Weatherproof 1.9" Mylar Diaphragm Constant Directivity Horn, 1" Exit | | Sensitivity | (1W/1M) 94.5 dBspl | | Dispersion | 90° Horizontal, 45° Vertical | | Impedance | Low (16 ohms) / High (70V) | | Power Input | Max: 225W @ 16 ohms; 128W @ 70V | | Power Settings | 70V: 128W, 64W, 32W, 16W, 8W | | Construction | Grille Material: Perforated Polypropylene
Cabinet Material: Black, Mineral-filled Polypropylene, with UV Inhibitor | | Connectors | Dual 4-Terminal Barrier Strips with Gold-plated, Rust-proof Screws | | Weight | 22 lb (9.97 kg) | | Dimensions | 10.25 x 17.87 x 11.75" (26 x 45.38 x 29.84 cm) | | | | Package Weight | 27.85 lb | | Box Dimensions (LxWxH) | 22.3 x 14.6 x 14.6" |
Rating100% users recommend this product to others. And what about you?
This product has already been rated by 22 owners. Add your rating and experience with the product.
