Product description The white AE-2s2 Wide-Angle Loudspeaker System from Bogen Communications is a wide-angle, 2-way, single-amped system designed for extended horizontal dispersion and high-fidelity response. The shape of the enclosure produces the wide coverage angle (165°) while minimizing sight-line obstructions. - Driver Complement
- Low Frequency: Dual Apogee 8" (204mm) permanent magnet conetype drivers are treated with a waterproofing compound, providing resistance to moisture, and enabling long-term stability of cone resonance and cone mass parameters
- High Frequency
- Dual Apogee 1" (25mm) horn-loaded compression drivers
- Input Connectors
- Neutrik NL4 MP Speakon connectors
- Compatible Processors
- DLC24 Digital Controller
- Grille
- Powder-coated, diamond-punched steel with acoustic foam covering
- Rigging Hardware
- Two 12-gauge steel nutplates, mounted one on either end, recessed, nominally flush; accepts 3/8"-16 thread; nutplates are backed with 12-gauge steel internal brackets
- Finish
- Textured, high-strength, white epoxy paint
- Enclosure Type
- Compound angular trapezoidal, optimally vented bass
- Cabinet Construction
- Multiply birch with stainless steel fasteners
In the Box Bogen Communications AE-2s2 Wide-Angle Loudspeaker System (White) Limited 2-Year Warranty Data Sheet PDF 274.6kbddexqvrrcdsefvbtawsyfzzbvbbrvssuffs Table of Contents
|
Upload User Manual
Have you got an user manual for the Bogen Communications AE-2s2 Wide-Angle Loudspeaker System in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersBogen Communications AE-2s2 Specs | Format | Single-amped/2-way/Electronically-coupled | | Dispersion | 165° x 45° | | Frequency Response | 1m on axis: 63 Hz to 19 kHz ±3 dB | | Maximum SPL | @1m: 114 dB cont./120 dB peak | | PTML (Peak Transient Mechanical Limit) | 131 dB | | Sensitivity | 1W @ 1m: 97.4 dB/200 Hz to 4 kHz | | Nominal Impedance | 16 Ω | | Maximum Power Handling | 120 W cont./480 W peak | | Dimensions (W x H x D) | Front: 32.0 x 9.9 x 10.0" (813.0 x 252.0 x 254.0 mm)
Rear: 32.0 x 8.5 x 10.0" (813.0 x 216.0 x 254.0 mm) | | Weight | 38.0 lb (17.3 kg) |
