User Manual for Bogen Communications AE-3s2 Loudspeaker System with Barrier Strip Connectors Click to enlarge the picture
Contents of the user manual for the Bogen Communications AE-3s2 Loudspeaker System with
- Product category: PA Speakers Bogen Communications
- Brand: Bogen Communications
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Bogen Communications PA Speakers
|
User manual for the Bogen Communications AE-3s2 Loudspeaker System with contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Bogen Communications product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Bogen Communications user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Bogen Communications product will considerably shorten its lifespan!
|
Product description The Bogen Communications white AE-3s2 Loudspeaker System from Apogee Sound International is a two-way, single-amped system that produces high acoustic output from a small enclosure. A pair can cover large hotel ballrooms or auditoriums for speech reproduction; adding a subwoofer (sold separately) provides wide range music reproduction. - Low Frequency
- One Apogee 10" (254mm) permanent magnet cone-type driver is treated with a waterproofing compound, providing resistance to moisture, and enabling long-term stability of cone resonance and cone mass parameters
- High Frequency
- One Apogee 1" (25mm) horn-loaded compression driver
- Input Connectors
- Gas-tight barrier strips
- Compatible Processors
- DLC24 Digital Controller
- Handles
- Two handles designed as an integral part of the enclosure (no moving parts)
- Grille
- Powder-coated, diamond-punched steel with acoustic foam covering
- Rigging Hardware
- Two 12-gauge steel nut plates, mounted one on either side, recessed, nominally flush; accepts 3/8"-16 thread, (10mm nut plate sold separately); nut plates are backed with 12-gauge steel internal brackets
- Finish
- Textured high-strength white epoxy paint
- Enclosure Type
- 20° trapezoidal, optimally vented bass
- Cabinet Construction
- Multi-ply birch with stainless-steel fasteners
In the Box Bogen Communications AE-3s2 Loudspeaker System with Barrier Strip Connectors (White) Limited 1-Year Warranty Data Sheet PDF 270kbrvbeuyvcdqefeywxbvtbyqetefvysy Table of Contents
|
Upload User Manual
Have you got an user manual for the Bogen Communications AE-3s2 Loudspeaker System with Barrier Strip Connectors in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersBogen Communications AE-3s2 Specs | Format | Single-amped / 2-way / Electronically-coupled | | Dispersion | 70° x 45° (H x V) | | Frequency Response | 70 Hz to 18 kHz ± 3 dB (1 m on axis) | | Maximum SPL | 121 dB continuous /127 dB peak (@ 1 m) | | PTML (Peak Transient Mechanical Limit) | 138 dB (1 W @ 1 m) | | Sensitivity | 99.5 dB / 200 Hz to 4 kHz | | Nominal Impedance | 8 Ω | | Maximum Power Handling | 300 W continuous / 1200 W peak | | Dimensions | Front (W x H): 12.50 x 16.25" (318.00 x 413.00 mm)
Rear (W x H): 10.00 x 16.25" (254.00 x 413.00 mm)
Depth: 10" (254 mm) | | Weight | 36.0 lb (16.4 kg) |
