User Manual for Bogen Communications AFI-4B Contractor Series Loudspeaker System with Dual Gas-Tight Barrier Strip Connectors Click to enlarge the picture
Contents of the user manual for the Bogen Communications AFI-4B Contractor Series Loudspeaker
- Product category: PA Speakers Bogen Communications
- Brand: Bogen Communications
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Bogen Communications PA Speakers
|
User manual for the Bogen Communications AFI-4B Contractor Series Loudspeaker contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Bogen Communications product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Bogen Communications user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Bogen Communications product will considerably shorten its lifespan!
|
Product description The Bogen Communications white AFI-4B Contractor Series Loudspeaker System with Dual Gas-Tight Barrier Strip Connectors from Apogee Sound International is a fully arrayable, bi-amped, 2-way loudspeaker suitable for clubs, discos, places of worship, theaters, and theme parks. It includes a 60° x 45° horn as well as bi-amplification capabilities. The horn, as well as the logo plate, is rotatable to allow alternative hanging positions. - Low Frequency
- One Apogee 12" (305mm) permanent magnet cone-type driver is treated with a waterproofing compound, providing resistance to moisture, and enabling long-term stability of cone resonance and cone mass parameters; also treated with Ferrofluid for greater power handling capability, lower distortion, and control of short-term impedance rise
- High Frequency
- One Apogee 1.75" (45mm) voice coil, 1" (25mm) exit horn-loaded compression driver treated with Ferrofluid
- Input Connectors
- Dual gas-tight barrier strip, screw type #8
- Compatible Processors
- Compatible with AFI Main Frame Controller Chassis (using either AFI-4/-4B/-4W/- 4WB Modules) or DLC24.
- Handles
- Two handles - one at the top, one at the bottom, designed as an integral part of the enclosure (no moving parts)
- Grille
- Highly durable, quality finish on perforated steel
- Rigging Hardware
- Fourteen rigging points, four each on top and bottom, two each on both sides and rear, all backed with 16-gauge steel; points can be type 3/8"-16 or M10 thread
- Enclosure Type
- 30° trapezoidal, optimally vented bass
- Finish
- Textured high-strength white epoxy paint
- Cabinet Construction
- Multi-ply hardwood
In the Box Bogen Communications AFI-4B Contractor Series Loudspeaker System with Dual Gas-Tight Barrier Strip Connectors (White) Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Bogen Communications AFI-4B Contractor Series Loudspeaker System with Dual Gas-Tight Barrier Strip Connectors in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersBogen Communications AFI-4 Specs | Format | Bi-amped / 2-way | | Dispersion | H x V: 60° x 45° (rotatable) | | Frequency Response | 58 Hz to 20 kHz ± 3 dB (1 m on axis) | | Maximum SPL | 122 dB continuous / 128 dB peak (@ 1 m) | | PTML (Peak Transient Mechanical Limit) | 139 dB | | Sensitivity | LF: 99 dB SPL/100 Hz to 1.4 kHz (1 W @ 1 m)
HF: 103 dB SPL/1.4 kHz to 5 kHz (1 W @ 1 m) | | Nominal Impedance | 8 Ω each driver | | Maximum Power Handling | LF: 200 W continuous / 800 W peak
HF: 75 W continuous / 300 W peak | | Dimensions | Front (W x H): 15.3 x 28.2" (389.0 x 716.0 mm)
Rear (W x H): 9.9 x 28.2" (252.0 x 716.0 mm)
Depth: 12.1" (307.0 mm) | | Weight | 53 lb (24 kg) |
