Product description The white Apogee Sound AFI-4W SX Loudspeaker System from Bogen Communications is a fully arrayable loudspeaker, versatile enough for clubs, discos, churches, theaters, and theme parks. Much of this versatility comes from the available options that include a 60 x 45° horn as well as bi-amplification capabilities. These horns, as well as the logo plate, are rotatable to allow alternative hanging positions. Driver Complement - Low Frequency: One Apogee 12.0" (304.8mm) permanent magnet cone-type driver is treated with a waterproofing compound, providing resistance to moisture, and enabling long-term stability of cone resonance and cone mass parameters; also treated with Ferrofluid for greater power handling capability, lower distortion, and control of short-term impedance rise.
- High Frequency: One Apogee 1.75" (44.45mm) voice coil, 1.0" (25.4mm) exit horn-loaded compression driver treated with Ferrofluid.
Handles - Two handles, one top and one bottom, designed as an integral part of the enclosure (no moving parts).
Rigging Hardware - Fourteen rigging points, four each on top & bottom, two each on both sides & rear, all backed with 16-gauge steel. Points can be type 3/8"- 16 or M10 threads.
Finish - Textured, high-strength, white epoxy paint finish with SX weather treatment for resistance to harsh environmental conditions.
In the Box Bogen Communications AFI-4W SX Loudspeaker System (White) Limited 2-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Bogen Communications AFI-4W SX Loudspeaker System in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersBogen Communications AFI-4 Specs | Format | Passive / 2-way | | Dispersion | H x V: 60 x 45° (rotatable) | | Frequency Response | 3.2' (1.0 m) on Axis: 58 Hz to 20 kHz ±3 dB | | SPL | Maximum at 3.2' (1.0 m):
121 dB continuous
127 dB peak | | PTML (Peak Transient Mechanical Limit) | 138 dB | | Sensitivity | 1 W at 3.2' (1.0 m): 99 dB SPL/ 100 Hz to 4 kHz | | Nominal Impedance | 8 Ω, each driver | | Maximum Power Handling | 200 W continuous
800 W peak | | Input Connectors | Barrier strip, screw type 8 | | Processor | Compatibility: AFI Main Frame Controller Chassis or DLC24 Digital Loudspeaker Controller The AFI Controller consists of an analog Main Frame & accepts 4 voicing modules. The DLC24 Digital Loudspeaker Controller is a digital engine with an analog surface. | | Grille | Highly durable, quality finish on perforated aluminum | | Enclosure Type | 30° trapezoidal, optimally-vented bass | | Cabinet | Construction: Multi-ply hardwood | | Dimensions | Front (W x H): 15.3 x 28.2" (388.6 x 716.2 mm)
Rear (W x H): 9.9 x 28.2" (251.6 x 716.2 mm)
Depth: 12.1" (307.3 mm) | | Weight | 53 lb (24 kg) |
