Product description The Infrared Wireless 2-Channel Microphone Voice Enhancement System from Bogen Communications offers professional performance and operating features for educational and institutional applications by enhancing a presenter’s voice to all corners of the room. The Enhancer System includes the BCWR Dual-Channel Infrared Receiver, BCWBT Bodypack Transmitter, BCLM Clip-On Lavalier Microphone, BCHM Headset Microphone, BCBM Bodypack Microphone, and two BCIRS Infrared Sensors. It uses infrared technology, eliminating the interference and crosstalk from adjacent rooms.
The Enhancer System helps presenters by reducing the effects of poor room acoustics and the weakening effect of voice traveling through air. Additional sensors, handheld microphones, rechargeable batteries and chargers are available separately to expand the system's capabilities. When integrated with Bogen’s wide range of amplifiers and speakers, the Enhancer provides an effective and flexible voice reinforcement system. Enhancer System - Infrared Wireless Microphone System designed for presenters in educational and institutional settings
- Two wide-angle, IR sensors allow for complete room coverage
- IR Sensors can be expanded to tailor coverage to every size room 1
Please Note: This feature requires additional BCIRS Infrared Sensors which are sold separately close - Unbalanced mixed audio output
- Flexible system configures to meet different needs in different settings
BCWR Dual-Channel Wireless Microphone Receiver - 2-Channel receiver offers a simultaneous 2-channel operation for 2 transmitters (Ch. A, Ch. B)
- Infrared signal reception LED indicators
- Channel A/B mixed audio output RCA-type connector
- Separate channel A and channel B volume controls
- Two IR sensor coaxial-type inputs
BCWBT Bodypack Transmitter - Wide-dispersion high-efficiency infrared emitter array LEDs in transmitters for optimum IR transmission
- Channel A/B Selector Switch
- 3.5mm locking jack for connection of body-pack, lapel, or headset microphones
- Microphone input volume control
- Belt clip and adjustable, neck-worn lanyard
- Requires 2 alkaline AA batteries or 2 NiMH AA rechargeable batteries (BCBRBP) 2
Please Note: 2 alkaline AA batteries are included while the BCBRBP Rechargeable Battery Pack is sold separately. close BCIRS Infrared Sensor - Multiple arrays of wide-angle infrared sensitive LEDs
- 35' connecting cable with coaxial-type connector
- Comes with mounting brackets
BCHM Headset Microphone - Lightweight adjustable boom arm
- Close-miked vocal pick-up
BCLM Lavalier Microphone - Close-miked vocal pick-up
BCBM Bodypack Microphone - Mounts directly to BCWBT Bodypack Transmitter
UPC: 765368370065 In the Box Bogen Communications Infrared Wireless 2-Channel Microphone Voice Enhancement System BCWR 2-Channel IR Wireless Microphone Receiver uvzqwsaxuyudwvyettwrucbvw BCWBT Body-Pack Transmitter with Lavalier BCHM Headset Microphone for Enhancer Wireless System Body-Pack Microphone for BCWBT Wireless Body-Pack Transmitter 2 x BCIRS Infrared Sensor with Mounting Brackets and 35' Cable 6' RCA Audio Cable Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Bogen Communications Infrared Wireless 2-Channel Microphone Voice Enhancement System in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersBogen Communications ENHANCER Specs | | | Mode | Infrared frequency modulated | | Receiving Channels | Dual-channels A & B | | Carrier Frequency | Ch. A: 2.0 MHz
Ch. B: 2.6 MHz | | Audio Frequency Response | 60 Hz to 12 kHz | | Signal to Noise Ratio | > 90 dB | | Audio Output | Mixer Output: 400 mV | | Range Of View | Up to 30.0' (9.4 m) | | Controls | Power On/Off (front)
Ch. A and B volume (rear) | | Connectors | IR sensor coaxial-type jacks, Ch. A/B (rear)
AC power input jack (rear)
Audio mixed output RCA-type jack (rear) | | Power Requirements | 16 VAC, 600 mA (via AC adapter) | | Power Consumption | 8 W | | Dimensions (W x H x D) | 10.6 x 2.0 x 7.4" (26.9 x 5.08 x 18.8 cm) | | Weight | 4.0 lb (1.81 kg) | | | | Carrier Frequency | Ch. A: 2.0 MHz
Ch. B: 2.6 MHz | | Audio Input | Compatible With:
BCBM Bodypack omnidirectional condenser microphone
BCLM Lavalier-type omnidirectional condenser microphone
BCHM Headset-type unidirectional condenser microphone | | Controls | On/Off switch, volume control, Ch. A/B select switch | | Connectors | 3.5 mm locking jack (Mic connection)
DC input charge jack | | Power Requirements | 2 x AA batteries (2.4 VDC) (included) | | Dimensions (W x H x D) | 2.6 x 3.9 x 1.7" (6.6 x 9.9 x 4.3 cm) | | Weight | Transmitter: 3.6 oz (102.0 g)
Headset: 1.1 oz (31.2 g) |
