User Manual for Bogen Communications SI35A Multi-Graphic Desktop Control Center Click to enlarge the picture
Contents of the user manual for the Bogen Communications SI35A Multi-Graphic Desktop Control
- Product category: Speaker Cases & Covers Bogen Communications
- Brand: Bogen Communications
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Bogen Communications Speaker Cases & Covers
|
User manual for the Bogen Communications SI35A Multi-Graphic Desktop Control contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Bogen Communications product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Bogen Communications user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Bogen Communications product will considerably shorten its lifespan!
|
Product description The SI35A Multi-Graphic Desktop Control Center from Bogen Communications provides fast, reliable and efficient intercommunication and tone signaling in small to medium-sized schools. The SI35A provides a 20W intercom amplifier to permit instant intercommunication with any speaker-equipped location, and a separate 35W program amplifier for simultaneous distribution of program material to other rooms or locations. The system also features an emergency page capability for emergency announcements to all stations at once.
The system provides complete facilities for distributing a variety of program materials from equipment such as microphones, CD player- AM/FM receiver, or other background music source (sold separately). Selection of program material, as well as its distribution to selected rooms is accomplished with simple push-button program selection and by following the color-coded guidelines. - Cost-effective communication for 25 to 75 rooms
- Can be furnished with 1, 2, or 3 room selector panels (each with 25 switches), to accommodate up to 25, 50, or 75 rooms (model SBA225, sold separately)
- Step-by-step instructions and color-coded guidelines for easy operation
- Instant emergency and all rooms announcements
- Remote emergency paging capabilities
- 20W intercom; separate 35W program channel
- Provision for time signaling, Telco and voice call-in
- Aural and visual monitoring of program material, as well as level controls
- Transmit a time tone for classroom change
- Emergency All-Call with a single push-button
- Emergency announcements take precedence over all system functions and are transmitted at a predetermined level
- Emergency paging from a remote telephone or microphone
- Teachers converse hands-free with the control center operator over their individual classroom speaker
- Calls to staff locations are announced by a supervisory tone signal, which repeats at regular intervals to indicate that the channel is open and the room is being monitored
- Classrooms can be equipped with call-in switches to call the control center, with options for privacy to voice call-in
- CD player-AM/FM receiver (sold separately) can be installed when the system capacity does not exceed 50 stations
- Sturdy desktop cabinet finished in an attractive simulated wood grain finish
UPC: 765368430257 In the Box Bogen Communications SI35A Multi-Graphic Desktop Control Center Limited 2-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Bogen Communications SI35A Multi-Graphic Desktop Control Center in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersBogen Communications SIC Specs | Output | Rated
Program: 35 WRMS
Intercom: 20 WRMS
25 V Balanced line, Line Out to Booster | | Frequency Response | Program: +1, -3 dB from 80 Hz to 15 kHz
Intercom: Shaped for maximum intelligibility | | Distortion | Less than 1% at rated power and bandwidth | | Input | Two Lo-Z balanced MIC: Hi-Z unbalanced AUX; Telco Page; 25V Booster | | Phantom Power | 15 VDC | | Input Sensitivity | Program: MIC Input: 300μV balanced Lo-Z; AUX: 100mV unbalanced Hi-Z (for rated output) Telco Page: 100mV unbalanced Hi-Z
Intercom: Listen Mode: 300 μV balanced Lo-Z (Console MIC: 1 mV unbalanced Lo-Z) | | Control | Front Panel: Program Selection: MIC 1, MIC 2, AUX; Level: Monitor/ Listen, Program; Distribution: All Rooms, Emergency, Press To Talk; Indicators: Program Talk/ Level LED
Rear Panel: Input Gain: MIC 1, MIC 2, AUX, Telco Page, Talk, Listen
Internal: Gain: Emergency Page, Supervisory Tone, Time Tone Enable/Disable: MIC 1/Console MIC; MIC 2/Telco Page, Phantom Power, Supervisory Tone, MIC 1/Monitor Mute | | Tone | Time Tone: 750 Hz
Supervisory Tone: Repeating, 500 Hz
Call-in Tone: Repeating; oscillates between 500 Hz and 750 Hz (Switching Frequency, 16 Hz) | | Power Requirements | 120 VAC, 60 Hz, 100 W maximum | | Cabinet | Simulated wood grain finish | | Panel | Black with color-coded lines and instructions for Intercom, Program, Emergency Page | | Operating Temperature | 0 to 130°F (-18 to 54.4°C) | | Dimensions (W x H x D) | 20.5 x 12.0 x 11.0" (520.7 x 304.8 x 279.4 mm) (with sloped top) | | Weight | 29.00 lb (13.15 kg) |
