User Manual for Bogen Communications V150 Power Vector Modular Input Amplifier 150W Click to enlarge the picture
Contents of the user manual for the Bogen Communications V150 Power Vector Modular
- Product category: Mixer/Amplifiers Bogen Communications
- Brand: Bogen Communications
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Bogen Communications Mixer/Amplifiers
|
User manual for the Bogen Communications V150 Power Vector Modular contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Bogen Communications product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Bogen Communications user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Bogen Communications product will considerably shorten its lifespan!
|
Product description The Bogen V150 Power Vector Amplifier 150W with 8 module bays for a wide array of inputs and outputs. Modules are available for signal processing and inputs such as: balanced and unbalanced inputs; stereo or mono; telephone systems/PBXs; transformer-isolated; microphones; tone generator; and bridging. The Power Vector automatically senses each module and inserts it into the signal path. A 5-position barrier strip allows for 4/8ohm or 25/70V output loads. When you need an amplifier with flexibility and reliability, the Power Vector V150 is the obvious choice. - 8 module bays for inputs and outputs
Each input has a independant volume control - 4 levels of priority between modules
- 125Hz Lo-cut filter for module 6
- 11-segment LED output level meter monitors the output level of the power amplifier with peak and average meter switch
- Grounded, un-switched AC convenience receptacle with a 500W maximum capacity provided for external equipment
- Remote volume control panel can operate motorized volume control (RVCP sold separately)
UPC: 765368391145 In the Box Bogen Communications V150 Power Vector Modular Input Amplifier 150W 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Bogen Communications V150 Power Vector Modular Input Amplifier 150W in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersBogen Communications V150 Specs | Power Output | 150W | | Distortion | <0.5% | | Frequency Response | Transformer: 45-20,000Hz
Direct output: 20-20,000Hz | | Signal to Noise Ratio | Fundamental: -94 dB
With Aux Module: -70 dB
With Mic Module: -60 dB
With Tel Module: -70 dB | | Output Impedance | Transformer-Coupled: 70V, 25V, 8 ohms (balanced or unbalanced)
Direct Coupled: 4 ohms | | Muting | 4 Steps: -60, -21, -10, 0dB | | Output Connections | Pre-EQ (RCA) x 1
Signal Processor (RCA) x 1
2 module bays | | Input Connections | 8 module bays | | Specialties | 500W unswitched grounded outlet | | Dimensions | 16.5 x 3.5 x 12" (419.1 x 88.9 x 304.8mm) | | Weight | 35 lbs (15.87kg) | | | | Package Weight | 36.0 lb | | Box Dimensions (LxWxH) | 18.0 x 7.5 x 2.5" |
