User Manual for Bon FM-055F 5.5" On-Camera Monitor Click to enlarge the picture
Contents of the user manual for the Bon FM-055F 5.5" On-Camera Monitor
- Product category: On Camera Monitors Bon
- Brand: Bon
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Bon On Camera Monitors
 |
User manual for the Bon FM-055F 5.5" On-Camera Monitor contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Bon product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Bon user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Bon product will considerably shorten its lifespan!
|
Product description Plug the Bon FM-055F 5.5" On-Camera Monitor into your camera and view a Full HD picture without any scaling. The 1920 x 1080 resolution LCD panel is great for HD workflows and beyond. Despite the monitor's compact design, it has powerful functionality. SDI and HDMI I/O offers cross conversion from input to output, ensuring that the FM-055F can be used in professional and prosumer workflows without a hitch. With 1/4"-20 mounts on all sides, the FM-055F can be positioned for optimal viewing on complex rigs. For even easier placement, an auto-image flip feature instantly reorients the image on the screen for right-side-up viewing. The included power supply or L-series battery plate can power the monitor in the studio or in the field, respectively. Other battery plates are available separately to accept popular DV batteries. - Monitoring Tools
- Check your focus, exposure, and other aspects of your video image with this monitor's built-in monitoring tools. Preferred monitoring tools can be set to custom function buttons for quick accessibility.
- False color
- Waveform
- Vectorscope
- DSLR full-screen
- Focus assist (whole/center-only)
- Tally LED
- Exposure range check
- Zoom settings
- Timecode display
- H/V delay
- Pixel-to-pixel mapping
- Zero/under/over scan
- Various markers (4:3, 1.85:1, and more)
- R/G/B/luma-only
- Internal pattern generator
- H/V level meter
- 16Ch audio level meters
- Automatic Image Flip
- Regardless of orientation, the FM-055F will automatically flip the on-screen image for proper viewing. Image flip can be manually set as well.
- HDMI-SDI Cross Conversion
- Whether you're working with professional broadcast equipment or consumer/prosumer gear for your production, you can easily integrate the FM-055F. The HDMI input can be converted to an SDI output for using prosumer gear in broadcast workflows, or alternatively, the SDI input can be converted to an HDMI output for monitoring on computer monitors or televisions.
- Color-Calibrated Screen
- The monitor's LCD screen is calibrated at the factory, offering accurate color temperature selections out-of-the-box including 3200K, 5600K, 6500K, and 9300K.
UPC: 889716000012 In the Box Bon FM-055F 5.5" On-Camera Monitor Power Supply AC Power Cord Single Sony L-Series Battery Mount for Bon FM-055F/RM-072S Monitor Acrylic Screen Protector Screen Cleaning Cloth Limited 1-Year Warranty User Manual PDF 958.6kbyqxwasvuzu Table of Contents
|
Upload User Manual
Have you got an user manual for the Bon FM-055F 5.5" On-Camera Monitor in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersBon FM-055F Specs | | | Display Size | 5.5" / 13.9 cm | | Active Area | 4.8 x 2.7" / 121 x 68 mm | | Screen Resolution | 1920 x 1080 | | Viewing Angle | Horizontal: 160°
Vertical: 160° | | Maximum Brightness | 450 cd/m2 | | Contrast Ratio | 1000:1 | | Dot Pitch | 0.063 x 0.06 mm | | Bit Depth / Color Support | 8-Bit (16.7 Million Colors) | | Image Controls | False Color, Focus Peaking, Image Flip, Pixel-to-Pixel Zoom, Screen Markers, Underscan, Waveform | | | | Video | 1 x BNC (3G-SDI) Output
1 x HDMI Type A Output
1 x BNC (3G-SDI) Input
1 x HDMI Type A Input | | Audio | 1 x 3.5 mm Headphone Output | | Built-In Speaker | 1 x 0.5 W | | Other I/O | 1 x Mini-USB | | Card Slot | None | | | | Video Format | SDI
DCI 2K: 23.98/24
1080p: 23.98/24/25/29.97/30
1080PsF: 23.98/24
1080i: 50/59.94/60
720p: 50/59.94/60
NTSC
PAL | | | | Battery Type | None | | Power Consumption | 10 W | | | | Operating Humidity | 20 to 80% | | Operating Temperature | 14 to 104°F / -10 to 40°C | | | | Dimensions (W x H x D) | 6.1 x 3.9 x 1.2" / 156 x 98 x 30 mm | | Weight | 0.8 lb / 365 g | | | | Package Weight | 1.95 lb | | Box Dimensions (LxWxH) | 8.2 x 5.9 x 4.8" |
