User Manual for Bosch C1-IN Rack Mount Card Cage Click to enlarge the picture
Contents of the user manual for the Bosch C1-IN Rack Mount Card Cage
- Product category: Signal Extenders Bosch
- Brand: Bosch
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Bosch Signal Extenders
|
User manual for the Bosch C1-IN Rack Mount Card Cage contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Bosch product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Bosch user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Bosch product will considerably shorten its lifespan!
|
Product description The Bosch C1-IN Rack Mount Card Cage is used to mount the CNFE2MC/IN media converter device either on a surface or onto a rack, and is capable of holding a maximum of 14 CNFE2MC/IN modules. It uses an integral, field replaceable universal power supply that operates at 120 VAC to 240 VAC, 50/60 Hz, and offers automatic self-resetting current overload protection that prevents the entire card cage from shutting down in case there is a fault in any 1 module. - Helps to mount the CNFE2MC/IN media converter device either on a surface or onto a rack
- Holds a maximum of 14 CNFE2MC/IN modules
- Uses an integral, field replaceable universal power supply that operates at 120 VAC to 240 VAC, 50/60 Hz
- Automatic self-resetting current overload protection - prevents the entire card cage from shutting down in case there is a fault in any 1 module
In the Box Bosch C1-IN Rack Mount Card Cage Power Cords (US/Europe/UK) 3 Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Bosch C1-IN Rack Mount Card Cage in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersBosch C1-IN Specs | LED Indicators | Red: Power is supplied
No LED lit: No power | | Electrical | Input Voltage: 90-264 VAC at 1 A maximum
Output Voltage: 9 VDC ± 5% at 6.5 A at 167°F (75°C)
Fusing: 1.25 A slow blow (rack power supply) (plug-in modules individually electronically fused)
Power Indicator: Red LED
AC Line Cord Detachable: IEC-connected. US, European, and UK power cords supplied | | Slots | Fourteen 1" (25 mm) rack slots available | | MTBF | >100,000 hours | | Operating Temperature | -40 ~ 167°F (-40 ~ 75°C) | | Dimensions (LxWxH) | 19 x 7.5 x 6" (48 x 19 x 15 cm) | | Weight | Approx. 7.5 lb (3.4 kg) | | | | Package Weight | 9.65 lb | | Box Dimensions (LxWxH) | 23.1 x 12.3 x 12.2" |
