User Manual for Broncolor Unilite 3200 W S Flash Head for Verso, Pulso, Topas, Grafit, Nano, Opus, Mobil Power Packs Click to enlarge the picture
Contents of the user manual for the Broncolor Unilite 3200 W S Flash
- Product category: Power Pack Heads Broncolor
- Brand: Broncolor
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Broncolor Power Pack Heads
|
User manual for the Broncolor Unilite 3200 W S Flash contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Broncolor product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Broncolor user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Broncolor product will considerably shorten its lifespan!
|
Product description The Broncolor 3200 watt/second Unilite flash head has a sturdy aluminium housing grip, and bayonet mount with automatic lock for interchangeable reflectors and various area lamps. Its plug-in flash tube has a ceramic socket and spring for a secure hold. The flash head can be fitted either with 1600 or 3200 w/s flash tubes. Suitable for AC voltages from 100 to 240 V thanks to the stabilized fan supply (must be fitted with a corresponding modeling lamp). It is also usable with the battery-powered Mobil power pack (without modeling light). A power supply for this flash head is required. - Compatible with almost every Broncolor power pack, including the battery-operated Mobil.
- The protecting glass is available in 5500° K or 5900° K as well as "clear" or "mat". Safer protecting glass holder thanks to mechanical lock. Umbrella holder.
- Integrated tilting head with locking lever.
- Equipped with thermal protection, and is fan cooled.
- Switch and fuse for modeling light.
In the Box Broncolor Unilite 3200 W/S Flash Head for Verso, Pulso, Topas, Grafit, Nano, Opus, Mobil Power Packs 3200 w/s flashtube (150004) 300W Modeling light with fuse (152004) 16.5' Head extension cable (154007) Protective cap 2 Year Manufacturer's Warranty excluding flashtube and modeling light Table of Contents
|
Upload User Manual
Have you got an user manual for the Broncolor Unilite 3200 W S Flash Head for Verso, Pulso, Topas, Grafit, Nano, Opus, Mobil Power Packs in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersBroncolor Unilite 3200 Specs Maximum Watt/Seconds | 3200 w/s, as equipped 1600 w/s possible | User Replaceable Flashtube | Yes, 3200 w/s included (150004), 1600 w/s possible | Changeable Reflector | Yes, Broncolor Standard Bayonet Mount | Circuit Protection | Fuse | Cable Length | 16.5' (5M), 32' available | Modeling Light Wattage | 100-120V: 300W with fuse included 220-240V: 650W with fuse available | Modeling Light On/Off Switch | Yes | Protective Glass Dome | Optional | Fan Cooled | Yes | Dimensions | ~11.6 x 4.75 x 5" (29.5 x 12.1 x 12.7cm) | Weight | 6.2lbs (2.8kg) with cable | | Package Weight | 8.35 lb | Box Dimensions (LxWxH) | 15.7 x 11.8 x 7.7" |
Rating100% users recommend this product to others. And what about you?
This product has already been rated by 49 owners. Add your rating and experience with the product.
