User Manual for Buffalo LinkStation 8TB 520DN 2-Bay NAS Server Click to enlarge the picture
Contents of the user manual for the Buffalo LinkStation 8TB 520DN 2-Bay NAS
- Product category: Network Attached Storage Drives Buffalo
- Brand: Buffalo
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Buffalo Network Attached Storage Drives
 |
User manual for the Buffalo LinkStation 8TB 520DN 2-Bay NAS contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Buffalo product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Buffalo user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Buffalo product will considerably shorten its lifespan!
|
Product description Built for home use, the LinkStation 8TB 520DN 2-Bay NAS Server from Buffalo is a customizable solution that is designed to serve as a data hub by making it easier to store, share, and secure digital content. It has an overall capacity of 8TB, which is made up of 2 x 4TB SATA II 3.5" NAS hard drives, and is further powered by a 1.1 GHz Realtek RTD1195N Dual-Core processor and 256MB of DDR3 RAM, giving this NAS the ability to simultaneously stream four HD movies via DLNA while backing up multiple computers. Connectivity to your network is accomplished using the Gigabit Ethernet port and other compatible external peripherals can be connected to the 520DN using its single USB 3.0 Type-A port.
For those who require RAID support, this NAS supports RAID 0 for enhanced data transfer speeds, or RAID 1 for 1:1 data redundancy. For those who do not require a RAID, JBOD is also available. The LinkStation 520DN is compatible with Windows, Mac, iOS, and Android platforms and also supports the TCP/IP protocol and SMB/CIFS, AFP, FTP/FTPS, and HTTP/HTTPS network file services. Included with this NAS is a network cable and an AC adapter. Protection is provided by a limited 3-year warranty. General Features - LinkStation's Private Cloud
- Buffalo's private cloud solution ensures your privacy and comes without any monthly fees. With a private cloud, your data stays protected in the physical location of your device and not offsite in a 3rd party data center, so your data is accessible and just a couple of keystrokes away. The LinkStation 520DN has large-capacity options and there are no limitations on daily transfer sizes, and no monthly cloud service fees.
- WebAccess Provides One-Click Access
- Buffalo's free WebAccess app makes it possible for you to create a private cloud for easy remote access and file sharing with anyone as long as you have access to the Internet. All you need is a smartphone or tablet and Buffalo's free Android, iOS, or Windows app to enjoy full access to the digital content on your LinkStation 520DN.
- User-Friendly Setup and Intuitive Web-Based Interface
- The LinkStation 520DN has a graphical user interface that simplifies setup and use of the system. Simply follow the step-by-step instructions and you're on your way to secure network storage within minutes.
- Premium-Grade HDDs for Performance & Reliability
- The LinkStation 520DN comes with premium-grade hard drives, providing improved performance and durability for always-on storing, sharing, and streaming files. In addition to powerful performance, these hard drives result in lower operating costs and have longer average lifetimes. All you have to do is select how much storage space you want.
- Designed to Minimize Power Consumption
- Who doesn't want lower utility costs? The LinkStation 520DN's power control feature includes on/off scheduling, Wake-on-LAN, and hard drive spin down. These features enable the 520DN to stop working when you do, reduce power consumption, and extend the product's lifespan.
- DLNA
- The LinkStation 520DN is DLNA-compatible, so you can stream content from your computer, tablet, or smartphone to smart televisions and devices that are also DLNA-compatible.
- Backup
- NovaBACKUP software from NovaStor is included for managing backups on PCs, while the LinkStation 520DN also works with Apple Time Machine and is ready for multi-client Mac backups.
- BitTorrent
- This LinkStation 520DN is compatible with BitTorrent peer-to-peer file sharing.
UPC: 747464132648 In the Box Buffalo LinkStation 8TB 520DN 2-Bay NAS Server (2 x 4TB) Network Cable AC Adapter Limited 3-Year Warranty More from Manufacturer udqvvexbsxywyzfc Table of Contents
|
Upload User Manual
Have you got an user manual for the Buffalo LinkStation 8TB 520DN 2-Bay NAS Server in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersBuffalo 520DN Specs | | | CPU | 1.1 GHz Realtek RTD1195N Dual-Core | | Total Installed Memory | 256 MB DDR3 | | | | Total Raw Capacity | 8 TB | | Included Drives | 2 x 4 TB 3.5" HDD | | | | Connections | 1 x RJ45 (Gigabit Ethernet)
1 x USB Type-A (USB 3.1 Gen 1 (5 Gb/s)) | | Compatible Drive Interface | SATA II | | RAID Modes | RAID 0, 1, JBOD | | | | Supported Protocols | AFP
CIFS/SMB
FTP
HTTP
HTTPS
SFTP | | Ethernet Standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u | | | | AC Input Power | 100 to 240 VAC, 50 / 60 Hz | | Power Consumption | 36 W (Maximum) | | | | Operating Temperature | 41 to 95°F / 5 to 35°C | | Operating Humidity | 20 to 80% | | | | Dimensions | 3.4 x 8.1 x 5.0" / 8.7 x 20.5 x 12.8 cm | | Weight | 5.5 lb / 2.5 kg | | | | Package Weight | 6.1 lb | | Box Dimensions (LxWxH) | 10.1 x 8.9 x 5.1" |
