Product description

• EOS C200 Cinema Camera (EF-Mount)
  • First Look:Canon Cinema EOS C200
  • The Canon Cinema EOS C200 and C200B Video Training Series: Shooting with the Camera
  • From Dock to Dish - Canon EOS C200
  • The Canon Cinema EOS C200 and C200B Video Training Series: Dual Pixel CMOS Autofocus Features
  Canon's EOS C200 EF Cinema Camera features a built-in EVF, 4" LCD screen, top handle, Super 35mm CMOS sensor, and Dual Pixel Autofocus. The EF lens mount on the EOS C200 offers compatibility not only with Canon's existing broad range of DSLR lenses but also with their line of EF-mount CN-E cinema prime and zoom lenses. The Super 35mm sensor is paired with Canon's Dual DIGIC DV 6 image processor, allowing it to capture and record up to DCI 4K resolution.
  The C200 can also record Canon's Cinema RAW Light internally via its single CFast card slot. The camera also incorporates two SD card slots for recording UHD 4K/HD MP4 video. A built-in EVF enables the camera to maintain a small footprint when you shoot. However, the included removable 4" LCD screen as well as the included top handle and camera grip make this camera versatile for larger shoots. You can output video via the camera's SDI output, and the built-in XLR connectors provide two channels of audio at line, mic, and mic+48V level. A built-in Ethernet connector provides input/output control.

  Main Features

  Canon Super 35mm CMOS Sensor
  • Modeled on the Super 35mm motion picture film standard, the Canon CMOS sensor has an active image size of 24.4 x 13.5mm. It features 4096 x 2160 resolution to deliver Cine 4K images, as well as supporting Ultra HD (3840 x 2160), and Full HD (1920 x 1080).
  Dual Pixel CMOS AF Technology
  • Provides continuous AF (Autofocus) function for all autofocus lenses, using Dual Pixel CMOS AF technology. A new AF Lock setting also lets you change the image framing while holding the desired focus. This feature is ideal for users who regularly shoot with smaller crews, who shoot moving subjects, or who want smoother, more natural-looking autofocus.

    Dual Pixel CMOS AF technology features a CMOS sensor that consists of an array of pixels that each feature two separate photodiodes. By continuously comparing their outputs during AF mode, phase-difference autofocus helps ensure non-blurred images and smooth focus transitions even when the talent and/or camera are moving. The new feature places a high priority on maintaining sharp focus while providing a natural, smooth autofocus movement with select Canon EF lenses - including newer-generation STM lenses - which offer even smoother and quieter operation.
  Dynamic Range, ISO Range
  • The C200 features a dynamic range of approximately 13 stops, and an ISO range of 160 to 25,600. You can also select an expanded ISO range of 100 to 102,400. It supports Wide DR Gamma, Canon Log and Canon Log 3.
  Dual Canon DIGIC DV 6 Image Processor
  • The camera features Dual DIGIC DV 6 processors to handle the internal data processing.
  Ultra High-Resolution EVF
  • The EOS C200 features a built-in 0.46", 1.23MP color EVF and 100% field of view coverage for comfortable viewing and accurate judgment of composition, focus, and color. The angle of the viewfinder is adjustable for additional user comfort.
  4" LCD Touchscreen Camera Grip and Top Handle
  • Included with the C200 is a removable 4" Touchscreen LCD viewfinder. Also included with the C200 is a camera control handgrip as well as a removable top handle.
  Rich Audio Controls
  • Built directly into the C200 are two XLR audio inputs with +48V phantom power, and a 3.5mm microphone terminal is also built into the camera. Audio is recorded uncompressed in 16-bit PCM format at 48 kHz for high fidelity sound. Both XLR inputs as well as the mic terminal have the option for automatic as well as manual gain control.
  Canon Cinema RAW Light
  • This codec allows you to record raw data internally to a CFast 2.0 card via the camera's single CFast card slot. The CFast card slot enables capturing DCI 4K in Canon's Cinema RAW Light format.
  MP4 Recording
  • • UHD 4K and Full HD recording onto SD cards is available via the two SD card slots.
    • Slow-motion recording, pre-recording, frame recording, interval recording
  Recording Functions
  • Relay recording, double slot recording
  High-Speed Shooting
  • You can choose to record at 120/100p when recording in Full HD.
  White Balance
  • AWB
    Kelvin setting (setting range: 2000K to 15000K/-20CC to +20CC)
    Daylight
    Tungsten
    Set A
    Set B
  Other Recording Functions
  • Custom picture setting
    Black balance adjustments
    Color bars
    Peaking display
    Zebra display
    My Menu setting
    Waveform monitor display
    Assignable buttons (1-17)
    Key lock
    Marker display
    Enlarged display
    Custom display
    Peripheral illumination correction
    GPS support (GP-E2)
    Monaural microphone
  Playback Operations
  • Normal playback, fast forward (at speeds of ×5, ×15, ×60), fast reverse (at speeds of ×5, ×15, ×60), frame forward, frame reverse, rec review
  Clip Display
  • 3 x 4 (clip) index screen (raw/MP4/Photo)
  UPC: 013803290035
• EF 24-105mm f/4L IS II USM Lens An advanced one-lens solution, the EF 24-105mm f/4L IS II USM is a Canon L-series zoom covering wide-angle to short-telephoto focal lengths and featuring a constant f/4 maximum aperture. The version II of this popular lens sports a redeveloped optical design, which includes four aspherical elements to significantly reduce distortion and spherical aberrations throughout the zoom range for great sharpness and accurate subject rendering. Individual elements feature an Air Sphere Coating, too, to suppress flare and ghosting for greater contrast and color accuracy in harsh lighting conditions.

  Complementing the refined optics, this 24-105mm f/4 also sports a ring-type USM and internal focusing mechanism to enable quick, quiet, and accurate autofocus performance, as well as full-time manual focus override. A four-stop-effective Image Stabilizer is also used to minimize the appearance of camera shake for sharper handheld shooting. Additionally, this lens is weather-sealed and has a protective fluorine coating on the exposed elements for use in trying environmental conditions.
  • Standard wide-angle to telephoto zoom lens is designed for use with full-frame Canon EF-mount DSLRs, however can also be used with APS-C models where it will provide a 38.4-168mm equivalent focal length range.
  • Constant f/4 maximum aperture maintains consistent illumination throughout the zoom range.
  • Four glass-molded aspherical elements, including one large-diameter double-sided glass-molded lens, help to minimize distortions and spherical aberrations throughout the zoom range in order to maintain edge-to-edge sharpness and illumination.
  • An Air Sphere Coating has been applied to individual elements to reduce backlit flaring and ghosting for greater contrast and color fidelity in strong lighting conditions.
  • An Optical Image Stabilizer helps to minimize the appearance of camera shake by up to four shutter speed stops to better enable working in low-light conditions and with slower shutter speeds.
  • A ring-type Ultrasonic Motor (USM), along with an internal focusing design, optimized focusing algorithms, and a high-speed CPU, is employed to deliver fast, precise, and quiet autofocus performance as well as full-time manual focus override.
  • Rounded ten-blade diaphragm contributes to a pleasing out of focus quality that benefits the use of shallow depth of field and selective focus techniques.
  • As a member of the esteemed L-series, this lens has a weather-resistant design that protects against dust and moisture to enable its use in inclement conditions. Additionally, fluorine coatings have also been applied to the front and rear lens elements for further protection against fingerprints and smudging.
  UPC: 013803274196

• LM-V1 4" LCD Monitor for Canon C200 & C300 Mk II

• LA-V1 LCD Attachment Unit for EOS C200

• HDU-2 Handle Unit for EOS C200/C200B

• GR-V1 Camera Grip for EOS C200

• Shoulder Strap

• CA-A10 Compact Power Adapter for EOS C300 Mark II, C200, and C200B Camcorders

• Single Battery Charger for EOS C300 Mark II, C200, and C200B Batteries

• Compact Power Adapter

• UN-5 Unit Cable for Canon EOS C200, C300 Mark II, C700, and XC15 (20"')

• Eyecup

• BP-A30 Battery Pack For EOS C300 Mark II, C200, and C200B

• Shoulder Strap

• Tape Measure Hook

• Thumb Rest

• Body Cap

• Limited 1-Year Warranty

• E-77 II 77mm Lens Cap

• Lens Dust Cap E (Rear)

• Lens Hood EW-83M for EF 24-105mm f/3.5-5.6 IS STM and EF 24-105mm f/4L IS II USM Lens

• LP1219 Soft Lens Case

• Limited 1-Year Warranty

Upload User Manual

Please enter here the link to the user manual of this product: OR Enter here the file with the user manual of this product from your computer/phone: (60MB max; Permitted formats: PDF) 0%

Technical parameters

• EOS C200 Cinema Camera (EF-Mount)

  Image Sensor Size	24.6 x 13.8 mm (Super35)
  Sensor Type	CMOS
  Sensor Resolution	4206 x 2340 (9.84 MP)
  Effective Sensor Resolution	4096 x 2160 (8.85 MP)
  Pixel Pitch	6.4 µm
  Color Filter	Bayer
  ISO	160 to 25,600 (Native) 100 to 102,400 (Expanded)
  Gain	-2 to 42 dB (Native) -6 to 54 dB (Expanded)

  Lens Mount	Canon EF
  Lens Communication	Yes, with Autofocus Support
  Built-In ND Filter	Mechanical Filter Wheel with 2 Stop (1/4), 4 Stop (1/16), 6 Stop (1/64) ND Filters
  Built-In Microphone Type	Mono
  Recording Media	1 x CFast 2.0 Card Slots 2 x SDXC Card Slots

  Raw Recording	Cinema RAW Light 12-Bit: 4096 x 2160 at 24/30 fps (1 Gb/s) 4096 x 2160 at 60 fps (1 Gb/s)
  Recording Modes	MP4 4:2:0 8-Bit: 3840 x 2160p at 24/30/60 fps (150 MB/s) 1920 x 1080p at 30/60/120 fps (35 MB/s)
  Audio Recording	4-Channel 16-Bit 48 kHz

  Video Connectors	1 x BNC (SDI) Output 1 x HDMI (HDMI 2.0) Output
  Audio Connectors	2 x 3-Pin XLR Mic Level (+48 V Phantom Power) Input 1 x 1/8" / 3.5 mm Stereo Mic Level Input 1 x 1/8" / 3.5 mm Stereo Headphone Output
  Other I/O	1 x 2.5 mm LANC Control Input 1 x RJ45 LAN

  Display Type	LCD
  Screen Size	4"
  Touchscreen	Yes
  Screen Resolution	1,230,000 Dots

  Screen Size	.46"
  EVF Resolution	1,770,000 Dots

  Battery Type	Canon BP-A Series
  Power Connectors	1 x 4-Pin LEMO Input

  Accessory Mount	1 x 1/4"-20 Female 1 x Cold Shoe Mount
  Dimensions	5.7 x 6 x 7" / 14.48 x 15.24 x 17.78 cm (Without Grip) 7 x 6 x 8" / 17.78 x 15.24 x 20.32 cm (With Grip)
  Weight	3.2 lb / 1.5 kg

  Box Dimensions (LxWxH)	18.4 x 14.4 x 12.8"

• EF 24-105mm f/4L IS II USM Lens

  Focal Length	24 to 105mm
  Maximum Aperture	f/4
  Minimum Aperture	f/22
  Lens Mount	Canon EF
  Format Compatibility	Full-Frame
  Angle of View	84 Rating 80% users recommend this product to others. And what about you? This product has already been rated by 71 owners. Add your rating and experience with the product. Discussion Ask our technicians if you have a problem with your settings, or if anything is unclear in the user manual you have downloaded. You can make use of our moderated discussion. The discussion is public and helps other users of our website who may be encountering similar problems. The discussion is empty - enter the first post Post a new topic / query / comment: Items marked with * are required. Your name *: E-mail : Subject *: Message *: Your email address will not be displayed. Do not forget to fill it in if you want to receive a reply to your enquiry/contribution. Processing of personal data in accordance with GDPR
