User Manual for Canon imageCLASS LBP6030w Monochrome Laser Printer Click to enlarge the picture
Contents of the user manual for the Canon imageCLASS LBP6030w Monochrome Laser Printer
- Product category: Laser Printers Canon
- Brand: Canon
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Canon Laser Printers
 |
User manual for the Canon imageCLASS LBP6030w Monochrome Laser Printer contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Canon product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Canon user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Canon product will considerably shorten its lifespan!
|
Product description Print from nearly anywhere in your home or small office with the built-in Wi-Fi connectivity of the imageCLASS LBP6030w Monochrome Laser Printer from Canon. It offers a resolution of 600 x 600 dpi that uses Canon's laser printing technology to produce an equivalent to 2400 x 600 dpi for detailed documents. Also, the unit is quite fast with a print speed of 19 ppm and a first print out time of <8 seconds. additionally, the wireless connectivity enables printing directly from a mobile device using canon app.
A 150-sheet input tray handles documents from 3.0 x 7.4" up to 8.5 x 14" and it has a rated monthly duty cycle of 5,000 pages. In addition to the wireless connectivity, the printer does have a standard USB 2.0 connection. - Energy Saver mode uses just 1.6 W of energy
- Secure network printing features
- Optional input trays allow for a maximum paper capacity of 800 pages
UPC: 013803217711 In the Box Canon imageCLASS LBP6030w Monochrome Laser Printer Starter Toner Cartridge 125 (~700 Pages) USB Cable Power Cord Software CD-ROM Documentation CD-ROM Limited 1-Year Warranty Brochure PDF 471.7kb More from Manufacturer Table of Contents
|
Upload User Manual
Have you got an user manual for the Canon imageCLASS LBP6030w Monochrome Laser Printer in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersCanon LBP6030w Specs | | | Printing Technology | Monochrome laser | | Maximum Resolution | 600 x 600 dpi (2400 x 600 dpi quality) | | Print Speed | 19 ppm | | First Print Out Speed | <8 seconds | | Print Color | Black | | Duplex Printing | No | | Toner Cartridge Compatibility | Cartridge 125 Black (~1,600 pages) | | Printer Duty Cycle | Monthly: 5,000 pages | | Print Features | Watermark, page composer, toner saver | | | | Paper Handling | Input tray
Output tray | | Paper Types | Plain, heavy, transparency, label, envelope (Com 10, Monarch, DL, C5) | | Paper Sizes | 3.0 x 7.4" to 8.5 x 14.0" (7.6 x 18.8 cm to 21.6 x 35.6 cm) | | Media Weight | 16-43 lb bond | | Paper Capacity | Input Tray: 150 sheets or 10 envelopes
Output Tray: 100 sheets | | | | Interface | USB 2.0
Wi-Fi IEEE 802.11b/g/n | | OS Compatibility | Windows 7, 8, 8.1, Server 2008, Server 2008 R2, Vista, Server 2003, XP, 2000, Server 2012
Mac OS X 10.4.9 and later
Citrix Presentation Server 4.5 (32/64-bit), XenApp 5.0 (32/64-bit), XenApp 6.0 (64-bit), XenDesktop 4.0 (32/64-bit), XenDesktop 5.0 (32/64-bit)
Linux | | Processor | Canon Custom Processor 528 MHz + 264 MHz | | Memory | 32 MB | | Printer Language | UFR II LT | | Security | IP filtering, MAC address filtering, Secure Sockets Layer (SSL), SNTP | | | | Control Panel | Three LED indicators
Two operation keys | | Warm-Up Time | 10 seconds or less
Recovery Time: 1 seconds or less | | Power Requirements | 120-127 VAC, 60 Hz | | Power Consumption | Max: 840 W or less
Operating: 320 W
Standby: 2.8 W
Energy Save: 1.6 W | | Typical Power Consumption | TEC: 0.5 kWh | | Acoustic Noise | Sound Power
Operating: 6.5 B or less
Standby: Inaudible
Sound Pressure
Operating: 49.3 dB
Standby: Inaudible | | Operating Conditions | Temperature: 50 to 86°F (10 to 30°C)
Humidity: 20 to 80%, relative non-condensing | | Dimensions | 14.3 x 9.8 x 7.8" (36.3 x 24.9 x 19.8 cm) | | Weight | 11 lb (5 kg) without cartridge | | | | Package Weight | 14.5 lb | | Box Dimensions (LxWxH) | 16.0 x 12.0 x 10.0" |
