User Manual for Cavision 4 x 4" Glass Filter Set

• Product category: Filter Kits Cavision
• Brand: Cavision
• Description and content of package
• Technical information and basic settings
• Frequently asked questions – FAQ
• Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
• Authorized service for Cavision Filter Kits

Product description

• 4 x 4" Linear Polarizer Filter The Cavision 4 x 4" Linear Polarizer Filter is compatible with filter holders that can accommodate 3mm-thick, 4 x 4" rectangular filters. It helps to reduce reflections and glare by filtering out light that has become polarized due to reflection from a non-metallic surface. The light from the sun naturally becomes partially polarized due to reflecting off electrons in air molecules, causing the light to scatter into what appears as haze. A polarizing filter arranges, and filters, this directionally polarized light perpendicularly to the reflected light, allowing for the absorption of much of this light. This results in a noticeable reduction of glare and reflections from non-metallic surfaces and an increase in the saturation of skies and foliage.

  A linear polarizer differs from a circular polarizer in that it does not contain an additional quarter wave plane. The addition of a quarter wave plane is to circularly polarize linearly polarized light for the use of auto focus and exposure functions. Due to how the light is broken down and filtered with a linear polarizer, in-camera auto focus and exposure accuracy become skewed during use. When the light becomes circularly polarized, it permits the use of these functions. This filter is recommended when not using in-camera exposure metering or autofocus.
  • Helps to reduce reflections and glare by filtering out light that has become polarized due to reflection from a non-metallic surface.
  • Polarizing filters arrange, and filter, directionally polarized light perpendicularly to the reflected light, allowing for the absorption of much of the light.
  • Clears up haze in distant landscapes and provides more saturated, vivid colors.
  • Strongest effect when used at a 90° angle from the sun.
  • Recommended when not using in-camera exposure metering or autofocus.
  • Non-coated.
  • 1.5 to 6x filter factor reduces exposure by 0.6 to 2.6 stops.
  • Glass construction.
  • Microfiber filter cloth included for filter maintenance as well as a soft pouch for storage and transport.
• 4 x 4" Soft-Edge Graduated Blue 0.3 Filter (1-Stop) The Cavision 4 x 4" Soft-Edge Graduated Blue 0.3 Filter is compatible with filter holders that can accommodate 4mm-thick, 4 x 4" rectangular filters. It can be used to add blue to a hazy or colorless sky. When used instead of a polarizer filter to enhance the sky within an image, the desired effect can be applied only to the sky, without any unwanted polarization or additional contrast to any part of the image. The filter is densest at the edge and tapers to clear by the middle, with a soft-edged line of transition between the dense and clear areas. This filter has up to a 0.3 density and reduces light from entering a lens by up to one stop.
  • • Adds blue to a hazy or colorless sky
    • Soft-edged line of transition between the dense and clear areas
    • 0.3 density and 2x filter factor provides up to a one-stop reduction of light in selective areas
    • Glass construction
    • Microfiber filter cloth included for filter maintenance as well as a soft pouch for storage and transport
• 4 x 4" Soft-Edge Graduated Orange 0.3 Filter (1-Stop) The Cavision 4 x 4" Soft-Edge Graduated Orange 0.3 Filter is compatible with filter holders that can accommodate 4mm-thick, 4 x 4" rectangular filters. This filter can be used to enhance an existing sunset within a scene or to simulate a sunset in order to enhance a hazy or colorless sky. The filter is densest at the edge and tapers to clear by the middle, with a soft-edged line of transition between the dense and clear areas. This filter has up to a 0.3 density and reduces light from entering a lens by up to one stop.
  • • Enhances an existing sunset within a scene or simulates a sunset in order to enhance a hazy or colorless sky
    • Soft-edged line of transition between the dense and clear areas
    • 0.3 density and 2x filter factor provides up to a one-stop reduction of light in selective areas
    • Glass construction
    • Microfiber filter cloth included for filter maintenance as well as a soft pouch for storage and transport

• Filter Wrap

• Filter Pouch

• Limited 3-Month Warranty

• Filter Wrap

• Filter Pouch

• Limited 3-Month Warranty

• Filter Wrap

• Filter Pouch

• Limited 3-Month Warranty

Upload User Manual

Please enter here the link to the user manual of this product: OR Enter here the file with the user manual of this product from your computer/phone: (60MB max; Permitted formats: PDF) 0%

Technical parameters

• 4 x 4" Linear Polarizer Filter

  Filter Type	Linear Polarizer
  Filter Factor	1.5 - 6 (0.6 - 2.6 Stop)
  Shape	Rectangle
  Rectangular Size	4 x 4" / 101.6 x 101.6 mm
  Filter Thickness	0.12" / 3 mm
  Filter Material	Glass
  Coatings	None

  Box Dimensions (LxWxH)	8.15 x 7.7 x 0.95"

• 4 x 4" Soft-Edge Graduated Blue 0.3 Filter (1-Stop)

  Graduation Color	Blue
  Shape	Rectangle
  Rectangular Size	4 x 4" / 102.0 x 102.0 mm
  Graduation Type	Soft Edge
  Filter Factor	2 (1 Stop)
  Filter Thickness	0.2" / 4 mm
  Filter Material	Glass

  Box Dimensions (LxWxH)	5.1 x 4.6 x 0.6"

• 4 x 4" Soft-Edge Graduated Orange 0.3 Filter (1-Stop)

  Graduation Color	Orange
  Shape	Rectangle
  Rectangular Size	4 x 4" / 102.0 x 102.0 mm
  Graduation Type	Soft Edge
  Filter Factor	2 (1 Stop)
  Filter Thickness	0.2" / 4 mm
  Filter Material	Glass

  Box Dimensions (LxWxH)	5.1 x 5.0 x 0.9"
