User Manual for Cavision 4 x 5.65" Combination Hot Mirror ND 1.2 Glass Filter Click to enlarge the picture
Contents of the user manual for the Cavision 4 x 5.65" Combination Hot
- Product category: Neutral Density (Solid) Cavision
- Brand: Cavision
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Cavision Neutral Density (Solid)
|
User manual for the Cavision 4 x 5.65" Combination Hot contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Cavision product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Cavision user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Cavision product will considerably shorten its lifespan!
|
Product description How to Use ND Filters: Tips, Tricks, and Special Effects Read More The Cavision 4 x 5.65" Combination Hot Mirror/ND 1.2 Glass Filter combines both a solid ND filter and a hot mirror filter into a single solution for greater efficiency in controlling exposures and reducing the amount of IR light contamination.
The 1.2 ND filter darkens the entire image, allowing you to photograph with longer shutter speeds or wider apertures than normally required. By providing a 4-stop reduction in exposure, this filter allows you to control depth of field and convey movement more easily. The hot mirror portion of the filter incorporates a dielectric mirror in order to filter out infrared light pollution that is common when photographing with a digital camera in strong infrared situations, helping to achieve a more neutral color balance.
This filter measures 4 x 5.65" / 101.6 x 143.5mm and is constructed from 4mm-thick glass. Included with your filter is a microfiber lens cleaning cloth and a vinyl storage pouch with a touch-fastening flap. - The solid neutral density aspect of the filter provides a 4 stop reduction in exposure. This 1.2 density creates a darkening of the entire image, allowing you to photograph with a wider aperture or slower shutter speed than normally required. By slowing your exposure time or increasing your aperture, you are able to control depth of field and convey movement more easily. Neutral density filters do not affect the coloration of the image and are ideal for pairing with other filters.
- The hot mirror aspect of this filter incorporates a dielectric mirror within the filter to combat infrared light pollution that becomes noticeable when making long exposures with a digital camera. This situation is also naturally prevalent when photographing near strong sources of infrared, such as fires and at sunset. The hot mirror filter, as well as 30-layer coating technology, effectively cuts out infrared wavelengths but does not interfere with visible red wavelengths.
In the Box Cavision 4 x 5.65" Combination Hot Mirror/ND 1.2 Glass Filter (4-Stop, 4mm Thick) Microfiber Lens Cleaning Cloth Vinyl Storage Pouch Limited 6-Month Warranty Introduction to ND Filters: The Basics BH Online Videos 05/29/2015 How to Use ND Filters: Beyond the Basics BH Online Videos 05/29/2015 Table of Contents
|
Upload User Manual
Have you got an user manual for the Cavision 4 x 5.65" Combination Hot Mirror ND 1.2 Glass Filter in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersCavision FTG4X565HM1.2 Specs | Filter Type | Solid ND Combination | | Combination Type | IR Attenuation | | Density | 1.2 (4-Stop) | | Rectangular Size | 4 x 5.65" / 101.6 x 143.5 mm | | Filter Thickness | 0.16" / 4 mm | | Filter Material | Glass | | | | Package Weight | 0.4 lb | | Box Dimensions (LxWxH) | 6.7 x 5.3 x 0.5" |
Rating60% users recommend this product to others. And what about you?
This product has already been rated by 19 owners. Add your rating and experience with the product.
