User Manual for Celestron Elements TrekCel 3300 Click to enlarge the picture
Contents of the user manual for the Celestron Elements TrekCel 3300
- Product category: Portable Battery Packs Celestron
- Brand: Celestron
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Celestron Portable Battery Packs
 |
User manual for the Celestron Elements TrekCel 3300 contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Celestron product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Celestron user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Celestron product will considerably shorten its lifespan!
|
Product description Designed for those who are on the go, the Celestron Elements TrekCel 3300 is an outdoor portable charging solution for your electronic gear. Its 2-in-1 ergonomic design features a 1W white LED flashlight with a brightness of 100 lumens, low/high light, flashing, and SOS modes, as well as a 3300mAh lithium-ion battery that can charge virtually any device that is compatible with USB, such as smartphones, tablets, MP3 players, and more. Device charging is accomplished using its 0.9A USB Type-A port, and when this battery pack is drained, it can be recharged using its 1.0A micro-USB port via your computer's USB port or an AC adapter.
The TrekCel's overall battery capacity can be monitored using four red LED indicators, while its output charging can be monitored using a green LED. It can be recharged in around 4 hours, can endure around 500 charge cycles, and is usually fully discharged in around 2 hours, based on use with a 1500mAh device,. When used as a dedicated flashlight, its battery will last up to 30 hours on low power and up to 17 hours on high power, with a beam distance of up to 74.8' on low mode and 111.5' on high mode. It is well-suited for use in temperatures ranging from 14 to 140°F and not using the battery for 6 months or more will have a negative effect on its life. General Features - Power Delivery Times
- iPhone 3 (1200mAh): 1.5 hours
iPhone 4 (1400mAh): 1.8 hours
iPhone 5 (1440mAh): 1.8 hours
HTC Wildfire (1300mAh): 1.6 hours
Blackberry 9800 (1300mAh): 1.5 hours
Samsung Galaxy Note (3100mAh): 2.5 hours UPC: 050234009324 In the Box Celestron Elements TrekCel 3300 Soft Carry Pouch Silicone End Caps Wrist Strap USB Cable (16.0" / 40.6cm) Nokia 2.0 Adapter Nokia 3.5 Adapter Mini-USB/MOT V3 Adapter Micro-USB Adapter Samsung D808 Adapter Sony Ericsson K750 Adapter iPhone 30-Pin Adapter Limited 2-Year Warranty User Manual PDF 1.8mb Table of Contents
|
Upload User Manual
Have you got an user manual for the Celestron Elements TrekCel 3300 in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersCelestron Elements TrekCel 3300 Specs | | | Input Charging Port | Micro-USB | | Output Ports | 1 x USB Type-A | | Cable Length | 16" / 40.64 cm | | | | Battery Chemistry | Lithium-Ion | | Capacity (Wh) | 16.5 Wh | | Capacity (mAh) | 3300 mAh | | Charging Time | 4 Hours | | Charge Cycles | 500 | | | | DC Input Power | 5 VDC at 1 A | | Port Output Power | 5.0 V, .9 A | | | | Built-In Functionality | Flashlight | | Operating Temperature | 14 to 140°F / -10 to 60°C (Recommended) | | Storage Temperature | 40 to 77°F / 4 to 25°C | | Dimensions (W x H x D) | 1.5 x 1.5 x 5.4" / 38.1 x 38.1 x 136.9 mm | | Weight | 6.2 oz / 175.8 g | | | | Package Weight | 0.65 lb | | Box Dimensions (LxWxH) | 7.7 x 6.6 x 2.2" |
