User Manual for Celestron Omni XLT 127mm f 10 Schmidt-Cassegrain EQ Telescope Click to enlarge the picture
Contents of the user manual for the Celestron Omni XLT 127mm f 10
- Product category: Catadioptrics (Cassegrains) Celestron
- Brand: Celestron
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Celestron Catadioptrics (Cassegrains)
|
User manual for the Celestron Omni XLT 127mm f 10 contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Celestron product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Celestron user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Celestron product will considerably shorten its lifespan!
|
Product description Celestron's Omni XLT 127mm f/10 Schmidt-Cassegrain EQ Telescope is ideal for users who want a compact and powerful observation platform that is able to achieve high magnifications for detailed views of the Moon and planets as well as have the ability to reach out past our solar system to discover deep-sky objects such as nebulae and galaxies.The Schmidt-Cassegrain design, coupled with the proprietary Starbright XLT optical coating system, corrects aberrations like comas and chromatic aberration to produce clear and crisp, high-contrast images with true color rendition. For its compact 11" length, it features a long 1250mm focal length, giving it a high magnification potential, and its large aperture ensures the resolution required to see dim deep-space objects that smaller apertures are unable to see. The scope is outfitted with an internal focusing mechanism that accepts the included 1.25" 90° star diagonal. Celestron includes a 25mm eyepiece that yields a moderate 50x magnification to get new users started.The included manual equatorial mount features large slow-motion knobs that make it easy to track objects even while wearing gloves, with setting circles on both axes for alignment and celestial navigation. The Omni mount includes a Vixen-style dovetail for mounting other optical tubes, and an adjustable-height stainless steel tripod with large and sturdy 1.75"-diameter legs and an accessory tray that acts as a leg spreader for the tripod to add stability and reduce vibrations. - Optical Tube Assembly
-
- 127mm aperture
- f/10 focal ratio
- 1250mm focal length
- Schmidt-Cassegrain optical path
- StarBright XLT optical coatings: Multi-layer aluminum/SiO2 (quartz)/TiO2 (titanium dioxide) mirror coatings with flat reflectivity across the light spectrum for both astrophotography/astroimaging and visual observation
- Multi-layer MgF2 (magnesium fluoride) and HfO2 (hafnium dioxide) anti-reflective lens coatings
- High-transmission water white glass corrector lens with 97.4% light transmission
- Resolution: 1.1 arcsec (Rayleigh); 0.91 arcsec (Dawes)
- Internal focusing mechanism
- Mount and Tripod
-
- Mount:
- Manual German equatorial
- Slow-motion control knobs for precise adjustments
- Manual release clutches for easy movement
- Setting circles for alignment and celestial navigation
- Vixen-style dovetail saddle
- Includes 4-pound and 7-pound counterweights
- Internal mounting for optional polar alignment scope
- Tripod:
- Strong and sturdy stainless steel legs
- Adjustable height to accommodate a variety of users and observing positions
- Spiked feet improve stability on soft or uneven ground
- Center tray holds eyepieces and accessories while locking legs in place for improved stability and vibration reduction
- Included Accessories
-
- Eyepiece:
- 1.25"-diameter barrel
- Accepts most 1.25" astronomical filters
- 25mm focal length produces 50x power
- 53' field of view at 1000 yards, 1° apparent angle of view
- Diagonal:
- 1.25" snout and eyepiece holder
- 90° angle places head in a comfortable viewing position when aimed at or near the zenith
- Star configuration corrects view horizontally, but not vertically
- Finderscope:
- Low 6x magnification ensures a wide field of view for easier alignment and faster star-hopping navigation
- 30mm objective won't add excessive weight or bulk to optical tube assembly and mount
- Mounting bracket included
UPC: 050234110846 In the Box Celestron Omni XLT 127mm f/10 Schmidt-Cassegrain EQ Telescope Omni CG-4 Mount eawutwyyuqbbfurtesx 25mm Eyepiece 90° Star Diagonal 6x30 Finderscope with Bracket Limited 2-Year Warranty Instruction Manual PDF 8.8mb Table of Contents
|
Upload User Manual
Have you got an user manual for the Celestron Omni XLT 127mm f 10 Schmidt-Cassegrain EQ Telescope in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersCelestron Omni XLT Specs | | | Optical Design | Schmidt Cassegrain | | Aperture | 127 mm / 5" | | Focal Length | 1250 mm | | Focal Ratio | f/9.8 | | Eyepiece Barrel Diameter | 1.25" | | Diagonal | Yes, 90
