Product description The Chief ConnexSys Video Wall Portrait Mounting System supports 42 to 80" displays up to 150 lb on a single strut channel for quick row-leveling. It can extend your display up to 13.4" from the wall and supports 200 x 100 to 800 x 400 mm mount patterns in portrait orientation. It also provides -2.5 to 4° tilt adjustment. This mount includes a rail and features tool-free ClickConnect latching to secure displays. PowerZone technology provides six points of adjustment in one easy-to-access location at the top of the mount. - Hang units on a single strut channel for quick row-leveling
- Reduced installation time, particularly for XL and recessed configurations
- Tool-free ClickConnect latching secures displays
- PowerZone provides six points of adjustment in one easy-to-access location at the top of the mount
- RapidDraw display release
- Kickstand provides 20° of bottom tilt access
- Rigid frame keeps displays where you set them, even after extending for service
- Adjustable home depth position locks screens in place to maintain alignment despite accidental bumps/pushes
UPC: 841872161167 In the Box Chief ConnexSys Video Wall Portrait Mounting System with Rail Limited 10-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Chief ConnexSys Video Wall Portrait Mounting System with Rail in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersChief LVS1UP Specs | | | Supported Screen Sizes | 42 to 80" / 106.7 to 203.2 cm | | Supported Weight Capacity | 150 lb / 68.2 kg | | Mounting-Hole Pattern | 200 x 100 to 800 x 400 mm | | Number of Displays Supported | 1 | | | | Tilt Adjustment | -2.5 to +4
