User Manual for Chrosziel LWS Baseplate for Sony FS5 with Virtus Mini Power Distribution Box Click to enlarge the picture
Contents of the user manual for the Chrosziel LWS Baseplate for Sony FS5
- Product category: Camcorder Supports & Rigs Chrosziel
- Brand: Chrosziel
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Chrosziel Camcorder Supports & Rigs
|
User manual for the Chrosziel LWS Baseplate for Sony FS5 contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Chrosziel product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Chrosziel user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Chrosziel product will considerably shorten its lifespan!
|
Product description Combining comfortable shoulder-mounting and power distribution, this Chrosziel LWS Baseplate + Virtus Mini Kit for the Sony FS5 lets you build an advanced rig with a simple, unified power solution. This kit is comprised of Chrosziel's LWS FS5 baseplate with 15mm rods, the Virtus Mini power distribution box, 15mm rear rods, and a rear-rod bracket.The LWS baseplate is the linchpin of this rig, supporting 15mm accessories and allowing for easy buildup of the FS5. The integrated shoulder pad is movable to achieve comfortable positioning and balance, and with the included rear rod bracket and 15mm rods, can be attached to Chrosziel's Quick-Lock plate or any VCT-14 plate.Essential for building your kit with electronic components, the Virtus Mini is a power distribution box which easily attaches to the rear rods with its integrated rod clamp. It effectively draws power from a single Sony BP-U battery and distributes that power to multiple devices simultaneously. The multiple outputs ensure that your entire rig only requires a single power source, reducing downtime due to battery swaps. The included two-pin LEMO to barrel connector jack allows for the FS5 to draw power from the Virtus Mini; cables for other devices can be purchased separately. - Power Distribution
- Working in collaboration with ACSE-GmBH, Chrosziel includes the Virtus Mini Power Distribution box to not only power your FS5 camera, but any other accessory on your rig that requires power, from a single source. Outputs offered on the Virtus Mini are a regulated, switchable 7.5/8.6V Hirose output, three unregulated 12V two-pin LEMOs, and two convenient USB outputs.
- Unified Design
- With this LWS setup, all the parts come together to form a unified, weight-balanced rig. With the baseplate extended, the rig mounts nicely to Chrosziel's separately available Quick-Lock tripod plate. While shoulder-mounted, the battery and the Virtus Mini combined create a counterweight that balances out the FS5, enabling longer shooting periods without tiring.
In the Box Chrosziel LWS Baseplate for Sony FS5 with Virtus Mini Power Distribution Box Lightweight Support for Sony PXW-FS5 with Rods Rear Rod Clamp for 401-FS7 & 401-FS5 Lightweight Supports 401-14 50mm Extension Rods (15mm Diameter) Virtus Mini Power Distribution Box Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Chrosziel LWS Baseplate for Sony FS5 with Virtus Mini Power Distribution Box in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersChrosziel FS5-VIRTUSKIT Specs | | | Battery Plate | 1 x Sony BP-U series | | Power Outputs | 1 x Hirose, regulated 7.5 / 8.6 VDC
3 x LEMO 2-pin, 12 VDC unregulated
2 x USB 5 VDC, 3 A |
