User Manual for ChyTV Multi-SDI Video Graphics Display System Click to enlarge the picture
Contents of the user manual for the ChyTV Multi-SDI Video Graphics Display System
- Product category: Character Generators & Graphic Solutions ChyTV
- Brand: ChyTV
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for ChyTV Character Generators & Graphic Solutions
 |
User manual for the ChyTV Multi-SDI Video Graphics Display System contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any ChyTV product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official ChyTV user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a ChyTV product will considerably shorten its lifespan!
|
Product description The 3 RU Multi-SDI Video Graphics Display System from ChyTV is designed for local cable channels, communities, municipalities, PEG, and other television and video distribution networks. In addition to SD-SDI input and output, the system supports HD-SDI input and output with graphic overlay on top of live video, giving facilities an upgrade path to transition from SD to HD. Additionally, full-screen graphics can be displayed with dynamic text, logos, and animations. A versatile playlist scheduler allows for dynamic programming. The supplied ChyTV Tools user interface software allows for direct control of single or multiple systems.
Featuring an internal MPEG clip player, the device has the ability to manipulate the video clip either in a window that is surrounded by graphics and text or to superimpose the message over the video background. Professional Crawl overlays are broadcast-quality, smooth, and easily modified. Multiple Crawls can display simultaneously and can include graphics and logos. - Live full-screen SD-SDI / HD-SDI input with text and graphic overlay
- Layered page elements include live video, clips, text, graphics, and backgrounds
- Full-screen SD/HD clips as animated backgrounds overlaid with dynamic text and graphics
- Dynamic real-time 3D text and graphics
- Squeeze and position clip player windows, including dynamic transitions
- Dynamic broadcast-quality effects such as text pushes, fades, and crawls
- Animated text, graphics, and logos using GIF, TGA, and MPEG
- Multiple text and graphic zones may be independently sized and positioned
- Page scheduling, including looping durations or specific day, date, and time control
- External data interfaces for real-time data updates such as news, sports, stock, and weather
- Interfaces with a variety of peripheral devices including RFID, touchscreen, contact-closure switches, and serial control
- Suitable for local community announcements, local weather, lower-third titling, community advertising, town meeting announcements, agendas and minutes, public service announcements, and emergency alerts
In the Box ChyTV Multi-SDI Video Graphics Display System (3 RU Chassis) Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the ChyTV Multi-SDI Video Graphics Display System in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersChyTV 7A00348-RK Specs | Digital Video Outputs | HD HDMI
HD/SD-SDI (BNC) | | Digital Video Inputs | HD HDMI
HD/SD-SDI (BNC) | | Video Formats | 1080i, 720p, 625, 525 | | Audio Outputs | 1 x HDMI
1 x Line | | Audio Input | 1 x HDMI
1 x Line | | Interfaces | USB 2.0
USB 3.0
RJ45 10/100/1000-BaseT, Ethernet | | Power Supply | 80 PLUS EPS-12V 550 W Mini Redundant Power Supply | | Dimensions | 5.0 x 16.0 x 16.5" / 12.7 x 40.6 x 41.9 cm | | Weight | 43 lb / 19.5 |
