Product description

• Customizable Geared Focus Ring Providing a way to add a standard cine-style focus gear to your lens, the CINEGEARS Customizable Geared Focus Ring is a strong yet flexible rubber gear strip that you customize to fit the circumference of your lens. The gear is delivered as a rubber strip slightly longer than 12" long, which would correspond to a focus ring barrel just under 4" in diameter.

  The strip comes pre-scored for accurate trimming and with pre-formed holes for the metal clip that turns the rubber strip into lens gear. The gear features 0.8 MOD teeth that interface with 32 pitch cine-style focus drive gears.
  • The 0.8 MOD gear teeth interface with industry standard 32 pitch cine-style follow focus drive gears.
  • You customize the flexible rubber strip to fit your lens. After cutting the strip to length, you butt the ends together and insert the metal clip to form the lens gear.
  UPC: 743724114584
• Single Axis Wireless Motor Power Cable The CINEGEARS Single Axis Wireless Motor Power Cable provides power to your motor from an optional power source outfitted with a D-tap connector. The cable features a D-tap connector on one end and a 2-pin LEMO connector on the other. The cable features plastic insulation, and it can handle from 12 to 28 VDC.
  • Approximately 44" long
  • LEMO connector prevents polarity reversal when use with CINEGEARS motor.
  UPC: 743724113969
• 4-Pin Start/Stop Cable for Sony F5/F55 The Cinegears 4-Pin Start/Stop Cable can be used in conjunction with the Cinegears Start/Stop Trigger or Cinegears Single Axis Wireless Follow Focus System to trigger your Sony F5/F55 cameras remotely.
• Hard Case with Foam Inserts for Single-Axis Kit The CINEGEARS Hard Case with Foam Inserts for Single-Axis Kit is a waterproof case that provides protection to your equipment from damage from falls and impact. The custom cut foam interior allows you to keep the components of your single axis wireless kit snug and secure during transport and storage. UPC: 743724114720
• Thick Focus Ring for Express Controller The Thick Focus Ring from CINEGEARS is for use with Express Controller. It is made of whiteboard material and held in place with three strong magnets.
• 2" Rod Bracket for Lens Control Motors (19mm) The CINEGEARS 2" Rod Bracket for Lens Control Motors mounts on a 19mm support rod and allows you to mount your CINEGEARS lens control motor on your rods and drive your lens's geared focus, zoom, or iris. It features a spring-loaded locking lever that allows you to tighten the bracket on the clamp, while at the same time securing the motor to the clamp.
  • Provides height adjustment when used with an optional CINEGEARS Lens Control Motor.
  • The 19mm clamp is designed to work specifically with 19mm support rods.
  • The spring-loaded locking levers allow you to tighten or loosen the clamps, even when you do not have room to rotate the lever through 360° of rotation. If the lever becomes blocked, you gently pull up on the lever, rotate it back, and lower the lever to continue tightening or loosening it.
  UPC: 743724114102

Also Includes

• Single-Axis Wireless Motor
Customizable Geared Focus Ring
• Limited 1-Year Warranty
Single Axis Wireless Motor Power Cable
• Limited 1-Year Warranty
4-Pin Start/Stop Cable for Sony F5/F55 wwvtvwvuvsscfxycfqebxf Hard Case with Foam Inserts for Single-Axis Kit
• Limited 1-Year Warranty
Thick Focus Ring for Express Controller 2" Rod Bracket for Lens Control Motors (19mm)
• Limited 1-Year Warranty
• Single-Axis Wireless Express Plus Controller
• 19 to 15mm Adapter Bushing
• Limited 3-Year Warranty on Controller and Motor
• Limited 1-Year Warranty on Cables, Bracket, Bushing, Marking Discs, and Case
