User Manual for Cisco RV325 Dual Gigabit WAN WF VPN Router Click to enlarge the picture
Contents of the user manual for the Cisco RV325 Dual Gigabit WAN WF
- Product category: Network Routers Cisco
- Brand: Cisco
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Cisco Network Routers
 |
User manual for the Cisco RV325 Dual Gigabit WAN WF contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Cisco product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Cisco user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Cisco product will considerably shorten its lifespan!
|
Product description Covering important network concerns like secure access and firewall protection, the RV325 Dual Gigabit WAN/WF/VPN Router from Cisco is designed to offer enhanced security with the convenience of VLAN connectivity. With a quick and easy setup thanks to the dual Gigabit Ethernet WAN ports and fourteen Gigabit Ethernet ports you can begin offering VLAN access to up to 40,000 connections simultaneously. In addition to the large number of connections, this router also supports an IPsec VPN throughput of up to 100 Mbps and an SSL VPN throughput of up to 20 Mbps. A simple to use browser-based user interface makes logging into a VLAN simple and easy while keeping the network secure thanks to an SPI firewall and strong hardware encryption. Configuration and management has also been simplified thanks to the included wizard based configuration tools. - Take advantage of enhanced web filtering to guard against malicious or non-work related websites
- Dual Gigabit Ethernet WAN ports allow load balancing and business continuity
- Affordable, high-performance Gigabit Ethernet ports enable rapid transfer of large files, supporting multiple users
- Dual USB ports support a 3G/4G modem or flash drive. The WAN can also fail over to the 3G/4G modem connected to the USB port
- SSL VPN and site-to-site VPN enable highly secure connectivity, making the Cisco RV320 perfect for remote employees and multiple offices
- Stateful packet inspection (SPI) firewall and hardware encryption provide strong security
- Wizard-based configuration tools can be used to establish network connectivity and manage security
UPC: 882658842757 In the Box Cisco RV325 Dual Gigabit WAN/WF/VPN Router Limited 2-Year Manufacturer Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Cisco RV325 Dual Gigabit WAN WF VPN Router in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersCisco RV325 Specs | Dual WAN | Dual Gigabit Ethernet ports
Failover
Load balancing | | Standards | 802.3, 802.3u
IPv4 (RFC 791)
IPv6 (RFC 2460) | | WAN Connectivity | Dynamic Host Configuration Protocol (DHCP) server, DHCP client, DHCP relay agent
Static IP
Point-to-Point Protocol over Ethernet (PPPoE)
Point-to-Point Tunneling Protocol (PPTP)
Transparent bridge
DNS relay, Dynamic DNS (DynDNS.org, 3322.org), DNS local database
IPv6 | | Routing Protocols | Routing Information Protocol (RIP) v1 and v2, and RIP for IPv6 (RIPng)
Inter-VLAN routing
Static routing
VLANs supported: 7 | | Network Address Translation (NAT) | Port Address Translation (PAT)
One-to-one NAT
NAT traversal | | Protocol Binding | Protocols can be bound to a specific WAN port for load-balancing purposes | | Network Edge (DMZ) | DMZ port
DMZ host | | USB Ports | Dual USB 2.0 ports (storage and 3G/4G modem support) | | | | Firewall | SPI firewall
Denial-of-Service (DoS) prevention: ping of death, SYN flood, IP spoofing, WinNuke | | Access Rules | Schedule-based access rule
Up to 50 entries | | Port Forwarding | Up to 30 entries | | Port Triggering | Up to 30 entries | | Blocking | Java, cookies, ActiveX, HTTP proxy | | Content Filtering | Static URL blocking of keyword blocking | | Secure Management | HTTPS web access to device manager
Username/password complexity enforcement | | VLAN | 802.1Q VLAN
17 x VLANs supported | | Web Filtering | Content filtering covering 27+ billion URLs | | | | IPsec Access Modes | 25 x IPsec site-to-site tunnels for branch office connectivity
25 x IPsec VPN tunnels via Cisco VPN client and third-party clients | | SSL VPN Tunnels | 10 x SSL VPN tunnels for remote client access | | PPTP VPN | 10 x PPTP tunnels for remote access | | Encryption | Data Encryption Standard (DES)
Triple Data Encryption Standard (3DES)
Advanced Encryption Standard (AES) encryption: AES-128, AES-192, AES-256 | | Authentication | MD5/SHA1 | | IPsec NAT Traversal | Supported for gateway-to-gateway and client-to-gateway tunnels | | VPN Pass-Through | PPTP, Layer 2 Tunneling Protocol (L2TP), IPsec | | Advanced VPN | Dead peer detection (DPD)
Split DNS
VPN backup
Internet Key Exchange (IKE) with certificate | | | | Service-based QoS | Rate control or priority | | Rate Control | Upstream/downstream bandwidth per service | | Prioritization Types | Application-based priority on WAN port | | Priority | Services mapped to one of two priority levels | | | | IPsec VPN Throughput | 100 Mbps | | SSL VPN Throughput | 20 Mbps | | Maximum Concurrent Connections | 40,000 | | | | Web User Interface | Browser-based device manager (HTTP/HTTPS) | | | | Management Protocols | Web browser (HTTP/HTTPS)
Simple Network Management Protocol (SNMP) v1, v2c, and v3
Bonjour | | Event Logging | Local log
Syslog
Email alert
Short Message Service (SMS) | | Upgradability | Firmware upgradable through the web browser
Import or export configuration files from or to a USB flash drive | | | | Ports | 14 x 10/100/1000 Gigabit Ethernet RJ-45 ports
1 x 10/100/1000 Gigabit Ethernet RJ-45 Internet (WAN) port
1 x 10/100/1000 Gigabit Ethernet RJ-45 DMZ/Internet (WAN) port | | Power Supply | 12 V / A | | Certifications | FCC Class B, CE Class B, UL, cUL, CB, CCC, BSMI, KC, Anatel | | Temperature & Humidity | Operating Temperature: 32 to 104°F / 0 to 40°C
Storage Temperature: 32 to 158°F / 0 to 70°C
Operating Humidity: 10 to 85% non-condensing
Storage Humidity: 5 to 90% non-condensing | | Dimensions | 9.6 x 7.0 x 1.8" / 243 x 177 x 45 mm | | Weight | Not specified by manufacturer | | | | Package Weight | 4.65 lb | | Box Dimensions (LxWxH) | 15.3 x 12.1 x 3.2" |
