Product description This Cokin Filter Holder and Filter Kit includes a Cokin Evo Aluminum X-Pro Series Filter Holder that is designed to accommodate multiple Cokin X-Pro Series, or 130mm wide, rectangular filters in order to help create the shot you envision. A Cokin Evo Circular Polarizer Filter is also included. It is designed for use with an Evo Aluminum X-Pro Series Filter Holder's front plate, or it can be placed directly on a lens that features 127mm front filter threads. When applied, it helps to reduce reflections and glare by filtering out light that has become polarized due to reflection from a non-metallic surface.
Use of the filter holder can be easily accomplished by first screwing a separately available, Cokin X-Pro Series Filter Holder Adapter Ring onto a camera lens. Adapter rings are available for lenses with 62mm, 67mm, 72mm, 77mm, 82mm, 95mm, 96mm, 105mm, or 112mm front filter threads. Cokin X-Pro Series filter holder adapter rings are also available for Hasselblad Bay 60 and Bay 70 lenses and Rolleiflex Bay VI lenses. The Cokin Universal X-Pro Series Filter Holder Adapter Ring may be used as well and is designed for lenses that are 60mm to 115mm in diameter. - Evo Aluminum X-Pro Series Filter Holder The Evo Aluminum X-Pro Series Filter Holder is designed to accommodate multiple Cokin X-Pro Series, or 130mm-wide, rectangular filters in order to help create the shot you envision. It can hold up to three rectangular filters that are each up to 2.3mm thick; or two rectangular filters that are each 3mm thick or 2.3mm thick, plus one 127mm screw-on filter. Alternatively, it can hold either two 3mm-thick rectangular filters along with another rectangular filter that is 2.3mm thick, or two 2.3mm-thick rectangular filters along with another rectangular filter that is 3mm thick.
Use of the filter holder can be easily accomplished by first screwing a separately available, Cokin X-Pro Series Filter Holder Adapter Ring onto a camera lens. Adapter rings are available for lenses with 62mm, 67mm, 72mm, 77mm, 82mm, 95mm, 96mm, 105mm, or 112mm front filter threads. Cokin X-Pro Series filter holder adapter rings are also available for Hasselblad Bay 60 and Bay 70 lenses and Rolleiflex Bay VI lenses. The Cokin Universal X-Pro Series Filter Holder Adapter Ring may be used as well, and is designed for lenses that are 60mm to 115mm in diameter.
The filter holder's back plate integrates the components that allow a Cokin X-Pro Series, or a 130mm-wide, rectangular filter to be secured to a lens with a compatible adapter ring. Five pairs of filter slots are included, up to three of which can be used to create a configuration that accommodates three rectangular filters that are each 2.3mm thick, or two 3mm-thick filters and one 2.3mm-thick filter, or two 2.3mm-thick filters and one 3mm-thick filter. These slots are attached to the front of the back plate while a pair of adapter ring slots for the back plate's rear snaps onto a Cokin X-Pro Series Filter Holder Adapter Ring. After being fitted onto an adapter ring, the back plate can be rotated 360°, permitting the use of graduated neutral density and other filters that are enhanced by varied positioning. Four brass screws held in place by four brass nuts attach the adapter ring slots and any filter slots in use to the back plate. Those screws can be loosened or tightened to vary the level of grip upon the inserted filters, which also can complement the use of graduated filters whose effect can be adjusted to better suit changing lighting conditions or creative demands by sliding them up or down within a filter slot.
Also included is a second plate that can be installed in front of the back plate, or in front of up to two of the back plate's filter slots. While in use, this front plate is attached to the same screws and nuts that hold the filter holder's main components together and provides the ability to place a screw-on 127mm filter at the very top of the filter holder assembly. This ensures that a filter such as a screw-on circular polarizer, which includes a filter ring that must be rotated in order to adjust the intensity of its effect, remains accessible.
To enable the use of 130mm-wide, 3mm-thick filters, a pair of spacers can be placed between the back plate and a pair of filter slots. Alternatively, the spacers can be placed between two pairs of filter slots so that a 130mm-wide, 3mm-thick filter can be installed ahead of a Cokin X-Pro Series, 130mm-wide, 3mm- or 2.3mm-thick filter. Together, these spacers help to ensure that a 3mm-thick filter is not obstructed along its side that faces the lens, whether by the back plate or by a 3mm- or 2.3mm-thick filter that is already installed.
To help prevent stray light, which could have unwanted effects on exposure, from coming in between the filter holder and a connected lens, a gasket is positioned along the front of the back plate. This gasket is designed to form a seal between the back plate and the first rectangular filter placed in front of it. -
- With a separately available Cokin X-Pro Series Filter Holder Adapter Ring, allows multiple Cokin X-Pro Series, or 130mm-wide, rectangular filters to be conveniently used on lenses with 62mm, 67mm, 72mm, 77mm, 82mm, 95mm, 96mm, 105mm, or 112mm front filter threads
- Usable with Cokin X-Pro Series filter holder adapter rings for Hasselblad Bay 60 and Bay 70 lenses and Rolleiflex Bay VI lenses
- Can hold up to three rectangular filters that are each 2.3mm thick, or two 3mm-thick filters and one 2.3mm-thick filter, or two 2.3mm-thick filters and one 3mm-thick filter
- Can be rotated 360°, permitting the use of graduated neutral density and other filters that are enhanced by varied positioning
- Grip on installed rectangular filters can be adjusted, allowing those filters to be moved up or down to better suit changing lighting conditions or creative demands
- While in use, 127mm screw-on filters are positioned at the very front of the filter holder assembly by a dedicated filter plate, ensuring that a filter such as a screw-on circular polarizer, which includes a filter ring that must be rotated in order to adjust the intensity of its effect, remains accessible
- Two pairs of spacers are included to ensure clearance behind a pair of filter slots used to hold a 130mm-wide, 3mm-thick filter
- Built-in gasket helps to prevent stray light, which could have unwanted effects on exposure, from coming in between a connected lens and a rectangular filter placed directly in front of it
- Durable and lightweight aluminum construction with brass fittings
- Evo 127mm Circular Polarizer Filter This Cokin Evo Circular Polarizer Filter is designed for use with an Evo Aluminum X-Pro Series Filter Holder's front plate, or it can be placed directly on a lens that features 127mm front filter threads. When applied, it helps to reduce reflections and glare by filtering out light that has become polarized due to reflection from a non-metallic surface.The light from the sun naturally becomes partially polarized due to reflecting off electrons in air molecules, causing the light to scatter into what appears as haze. A polarizing filter arranges, and filters, this directionally polarized light perpendicularly to the reflected light, allowing for the absorption of much of this light. This results in a noticeable reduction of glare and reflections from non-metallic surfaces, and an increase in the saturation of skies and foliage.
A circular polarizer differs from a linear polarizer in that it contains a quarter wave plane in addition to the linear polarizing filter. Due to how the light is broken down and filtered with a linear polarizer, auto focus and exposure accuracy become skewed during use. When the light becomes circularly polarized, it permits the use of these functions.
Cokin Evo circular polarizer filters are constructed from Schott glass for increased optical clarity as well as color fidelity, and promote nearly flat attenuation of visible and UV light. This 127mm Evo circular polarizer filter features a durable, lightweight, 7.50mm-thick aluminum-alloy filter ring assembly with a front ring that can be rotated to adjust the intensity of the polarization effect. These rings minimize the potential for vignetting, and the front ring also includes corresponding 127mm front filter threads for use with other screw-on filters.
To help eliminate internal ghosting and reflections, each glass surface of the 127mm Evo Circular Polarizer Filter features 16 layers of Cokin's EVERCLEAR 5 anti-reflection coating. These coatings are resistant to oil, dust, dirt, and scratches, offering greater protection to the filter and helping it to stay clean for longer than with uncoated filters. The coatings are also hydrophobic, resulting in an improved beading effect when in contact with water for greater cleaning efficiency. -
- Compatible with a Cokin Evo Aluminum X-Pro Series Filter Holder's front plate or a lens that features 127mm front filter threads.
- Helps to reduce reflections and glare by filtering out light that has become polarized due to reflection from a non-metallic surface.
- Polarizing filters arrange, and filter, directionally polarized light perpendicularly to the reflected light, allowing for the absorption of much of the light.
- Clears up haze in distant landscapes and provides more saturated, vivid colors.
- 16-layer Cokin EVERCLEAR 5 multi-coating prevents internal ghosting and reflections; is oil, dust, dirt, as well as scratch resistant; and provides an improved beading effect with water for more efficient cleaning.
- Approximately 45% average light transmission.
- 2x filter factor reduces exposure by 1 stop.
- Constructed from Schott glass for optical clarity.
- Slim, 7.50mm-thick, aluminum-alloy filter ring assembly helps to prevent vignetting, while remaining lightweight.
- Side knurling to provide a more textured grip when mounting or removing from a lens, as well as when rotating the front filter ring to adjust the intensity of the polarization effect.
- 127mm front filter threads allow for use with other filters.
- Padded pouch for storage and transport.
In the Box Bundle Items Evo Aluminum X-Pro Series Filter Holder sqxqaqtaacayca - 10 x Filter Holder Slots for Rectangular Filters
- Filter Holder Font Plate for 127mm Screw-On Filter
- 2 x Adapter Ring Slots for Filter Holder Back Plate
- 4 x Spacers for 3mm Rectangular Filter
Evo 127mm Circular Polarizer Filter Table of Contents
|
Upload User Manual
Have you got an user manual for the Cokin Evo Aluminum X-Pro Series Filter Holder and 127mm Circular Polarizer Filter Kit in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parameters - Evo Aluminum X-Pro Series Filter Holder
| Material | Filter Holder Plates: Aluminum
Filter Holder Slots: Nylon
Adapter Ring Slots: Nylon
Spacers: Nylon
Screws: Brass
Nuts: Brass | | Compatibility | Adapter Ring: Cokin X-Pro Series Filter Holder Adapter Ring
Filters: Accepts up to three rectangular filters (130mm-wide, 2.3mm-thick), up to two rectangular filters (130mm-wide, 3mm or 2.3mm-thick) plus one 127mm screw-on filter, up to three rectangular filters (130mm-wide, two 3mm and one 2.3mm-thick), or up to three rectangular filters (130mm-wide, two 2.3mm and one 3mm-thick) | | Rotating | Yes, 360° | | Dimensions | With up to Two 2.3mm-Thick Filters: 5.8 x 5.8 x 1.0" / 148.0 x 148.0 x 25.0 mm
With Two 3.0mm-Thick Filters and One 2.3mm-Thick Filter: 5.8 x 5.8 x 1.2" / 148.0 x 148.0 x 30.0 mm | | Weight | Without Front Plate: 3.5 oz / 100.0 g
With Front Plate: 5.5 oz / 155.0 g | | | | Box Dimensions (LxWxH) | 7.8 x 6.3 x 2.1" | - Evo 127mm Circular Polarizer Filter
| Filter Type | Circular Polarizer | | Filter Factor | 2 (1 Stop) | | Shape | Circle | | Circular Size | 127 mm | | Rotating | Yes | | Front Accessory Thread / Bayonet | 127 mm | | Filter Thickness | 0.30" / 7.50 mm | | Physical Feature | Slim | | Filter Material | Glass | | Coatings | Multi-Coating | | | | Box Dimensions (LxWxH) | 6.5 x 6.5 x 1.0" |
