User Manual for Cokin Z-Pro Series Black and White Filter Kit Click to enlarge the picture
Contents of the user manual for the Cokin Z-Pro Series Black and White
- Product category: Black & White Contrast Cokin
- Brand: Cokin
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Cokin Black & White Contrast
|
User manual for the Cokin Z-Pro Series Black and White contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Cokin product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Cokin user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Cokin product will considerably shorten its lifespan!
|
Product description This Cokin Z-Pro Series Filter Kit contains four filters that can be used individually to improve the results of your black and white photography. The included filters consist of a yellow filter, an orange filter, a red filter and a green filter. Each filter can be used to increase image contrast between colors within a scene that match or are analogous to the filter's color versus colors within a scene that are complementary to filter's color. Additionally, the green filter helps to effectively separate various hues among green-colored subjects into black-and-white tones.
To allow these filters to be placed in front of a lens, a separately-available Z-Pro Series filter holder and a Cokin Z-Pro Series lens adapter ring are required. Each filter is made of durable, optical resin (CR39) and measures 100 x 100 x 1.6mm. - Z-PRO 001 Yellow Resin Filter The Cokin Z-PRO 001 Yellow Resin Filter is normally used to establish a noticeable increase in contrast when using black and white film. This filter is specifically adapted to the Z-PRO Filter Holders and designed for medium format cameras as well as wide angle focal lengths below 20mm. This series is also well adapted to Broadcast. The Z-PRO Series is recommended for focal lengths of 20mm onwards (in the 35mm format). This filter is made of CR39 Resin which is a reputable lightweight and shock-resistant optical material also used for ophthalmic glasses.
- Especially useful for added contrast between blue sky with clouds and foreground
UPC: 085831700015 - Z-PRO 002 Orange Resin Filter The Cokin Z-PRO 002 Orange Resin Filter is a deep orange filter that darkens blue, violet, green and yellow-green. It is particularly useful for all landscape and architectural photography (on black and white film) requiring vivid contours. The sky is distinctly toned with the clouds clearly contrasted against it. It is suitable for landscapes and nature scenes. Cokin Z-PRO Filters are made from CR39 Resin which is a reputable lightweight and shock-resistant optical material also used for ophthalmic glasses.
- Especially useful for clear contrast between blue sky with clouds and foreground
- Enhances landscapes, marine scenes and aerial photography
UPC: 085831700022 - Z-Pro 003 Red Resin Filter This Cokin Z-Pro 003 Red filter is ideal for strong contrast improvement since it absorbs green and blue completely and enhances red. In addition to contrast control, red filters enhance skin tones, tonal corrections and are effective for more dramatic landscapes. When combined with a polarizer, the resulting image will increase the saturation of clouds making it appear that a storm is threatening.The Z-PRO Series is recommended for focal lengths of 20mm onwards (in the 35mm format). This filter is made of CR39 Resin which is a reputable lightweight and shock-resistant optical material also used for ophthalmic glasses.
- Clouds are dramatically improved almost to the mood of a thunderstorm; darkens blue sky creating dramatic contrast between sky and clouds
- It is more effective in cutting through haze, and moonlight effects are easily accomplished; creates greater contrast between foliage and flowers
- It is also suited for infrared photography
UPC: 085831700039 - Z-Pro 004 Green Resin Filter The Z-Pro 004 Green Resin Filter from Cokin is designed to create more contrast in Black-and-White images. It is ideal for landscape and nature photography, because it lightens greens and darkens reds. Therefore, making foliage appear brighter and creates separation between the dark and light tones.The filter is square in shape and the width is 130mm, which is only compatible with the Z-Pro Series Filter Holder. The filter has a filter factor of 3.5, so the exposure should be increased by 2 & 2/3 of a stop to compensate. CR39 Resin was used to make the Cokin filter. UPC: 085831700046
In the Box Bundle Items Z-PRO 001 Yellow Resin Filter fbeqysszcwrudatqcsfryqfycurdvuyadvuu Z-PRO 002 Orange Resin Filter Z-Pro 003 Red Resin Filter Z-Pro 004 Green Resin Filter
Also Includes Table of Contents
|
Upload User Manual
Have you got an user manual for the Cokin Z-Pro Series Black and White Filter Kit in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parameters - Z-PRO 001 Yellow Resin Filter
| Type | Z-PRO Yellow | | Size | 100 x 150mm (4 x 6"), 1.5mm thick | | Grade | Not Applicable | | Filter Factor | 2 (+1 stop) (approx) | | Multi-Coated | No | | Rotating | No | | Effect | Contrast control, enhanced skin tones, tonal corrections and more dramatic landscapes; Noticeable increase in contrast with black and white films | | Application | Offers the most correct tonal range contrast to produce natural clouds against blue skies | | Color Temperature | Not Specified by Manufacturer | | Construction | CR39 Resin | | Front Filter Thread Size | Not Applicable | | Front Lens Cap Size | Not Applicable | | | | Box Dimensions (LxWxH) | 6.8 x 4.8 x 0.3" | - Z-PRO 002 Orange Resin Filter
| Type | Z-PRO Orange | | Size | 100 x 150mm (4 x 6"), 1.5mm thick | | Grade | Not Applicable | | Filter Factor | 4 (+2 stops) (approx) | | Multi-Coated | No | | Rotating | No | | Effect | Renders sky dramatically darker | | Application | Contrast control, enhanced skin tones, tonal corrections and more dramatic landscapes | | Color Temperature | Not Applicable | | Construction | CR39 Resin | | Front Filter Thread Size | Not Applicable | | Front Lens Cap Size | Not Applicable | | | | Box Dimensions (LxWxH) | 6.7 x 4.7 x 0.5" | - Z-Pro 003 Red Resin Filter
| Type | Red | | Size | 100 x 100mm (4 x 4"), 1.5mm thick | | Grade | 25 | | Filter Factor | 3 (+2 stops) (approx) | | Multi-Coated | No | | Rotating | No | | Effect | Absorbs green and blue completely and enhances red | | Application | Create dramatic sky effects, emphasizing cloud contrast for landscapes
Simulate a moonlit scene at midday with slight underexposure
Use with infrared film to yield extreme contrast with skies, turn foliage white and cut through fog and haze | | Color Temperature | Not Specified by Manufacturer | | Construction | CR39 Resin | | Front Filter Thread Size | Not Applicable | | Front Lens Cap Size | Not Applicable | | | | Box Dimensions (LxWxH) | 6.772 x 4.803 x 0.472" | - Z-Pro 004 Green Resin Filter
| Type | B&W contrast filter | | Size | 130mm (5") | | Filter Factor | 3.5 (+2 2/3) | | Multi-Coated | No | | Effect | Lightens greens and darkens reds | | Application | Landscape and nature photography | | Compatibility | Z-Pro series filter holder | | Material | CR39 resin | | | | Box Dimensions (LxWxH) | 7.0 x 5.0 x 0.5" |
